LM4201TADDC PFXLM4201TADDC Front Overlay Touch Membrane
LM4201TADDC PFXLM4201TADDC Front Overlay Touch Membrane
LM4201TADDC PFXLM4201TADDC Front Overlay Touch Membrane
LM4201TADDC PFXLM4201TADDC Front Overlay Touch Membrane
LM4201TADDC PFXLM4201TADDC Front Overlay Touch Membrane
LM4201TADDC PFXLM4201TADDC Front Overlay Touch Membrane
Model
LM4201TADDC PFXLM4201TADDC

Item specifics

Brand
Proface
Size
3.5 inch
Warranty
365 Days
Product Line
Proface LT4000M Series
Supply
LT4000M Touch Screen Monitor Front Overlay
Part Number
LM4201TADDC PFXLM4201TADDC
Shipping
2-4 workdays

Review

Description

Proface LT4000M LM4201TADDC PFXLM4201TADDC Protective Film Touch Membrane

Order each part separately is available

Proface LT4000M LM4201TADDC PFXLM4201TADDC Front Overlay HMI Panel Glass Repair Replacement

The following rules must be applied when wiring a LM4201TADDC PFXLM4201TADDC Touch Membrane Protective Film LT:
 Input/Output and communication wiring must be kept separate from the power wiring. Route these 2 types of wiring in separate cable ducting.
 Verify that the operating conditions and environment are within specification.
 Use proper wire sizes to meet voltage and current requirements.
 Use copper conductors.
 Use twisted-pair, shielded cables for analog, and/or fast Input/Output.
 Use twisted-pair, shielded cables for networks, and fieldbus.
 For the power connector, refer to DC power supply wiring diagram.
 When terminals A2 and B2 (signal name: Q1, Q0) are wired to external I/O, use the same power source for external I/O and the LM4201TADDC PFXLM4201TADDC Front Overlay HMI Panel Glass LT. Refer to Power Supply Connections.
 If you use a temperature sensor with thermocouple inputs, make sure you use the compensation cable.
 Prevent temperature changes to the thermocouple connection terminal. Correct temperature measurement may not be possible if the thermocouple cold junction (LT's thermocouple compensation wiring to the connection terminal) experiences temperature changes.


Be aware of the following items when building the LM4201TADDC PFXLM4201TADDC Protective Film Touch Panel LT into an end-use product:
• The LT unit's rear face is not approved as an enclosure. When building the LT unit into an end-use product, be sure to use an enclosure that satisfies standards as the end-use product's overall enclosure.
• The LM4201TADDC PFXLM4201TADDC Protective Film Touch Digitizer Glass LT unit must be used indoors only.
• Install and operate the LM4201TADDC PFXLM4201TADDC Front Overlay Touch Membrane LT with its front panel facing outwards.
• If the LT is mounted so as to cool itself naturally, be sure to install it in a vertical panel. Also, it's recommended that the LT should be mounted at least 100 mm away from any other adjacent structures or machine parts. The temperature must be checked on the final product in which the LT is installed.
• For use on a flat surface of a Type 4X (Indoor Use Only) and/or Type 13 Enclosure.




Specifications:

The table below describes the parameters of the Proface LM4201TADDC PFXLM4201TADDC Protective Film Touch Screen Panel HMI Machine.

Brand: Proface
Display Resolution: 320 x 240 pixels
Part Number: LM4201TADDC
Storage Humidity: 10%RH to 90%RH (non-condensing)
Touch Size: 3.5"
Display Type: TFT Color LCD
Power Supply: 24 V DC
Product Line: Proface LT4000M
Storage Temperature: -20°C to 60°C
Warranty: 365 Days


Related Proface LT4000M Series HMI Part No. :

Pro-face LT4000M Description Inventory status
LM4201TADAC Pro-face LT4000M HMI Panel Glass Protective Film Available Now
LM4201TADAK Proface LT4000M Front Overlay Touch Screen Monitor In Stock
LM4201TADDC Proface LT4000M Touch Screen Protective Film Replacement In Stock
LM4201TADDK Proface LT4000M Protective Film Touch Panel Repair Available Now
LM4301TADAC Proface LT4000M Protective Film Touchscreen Repair In Stock
LM4301TADAK Proface LT4000M HMI Touch Screen Glass Protective Film Available Now
LM4301TADDC Proface LT4000M Touch Screen Panel Front Overlay Repair In Stock
LM4301TADDK Pro-face LT4000M Front Overlay Touch Membrane In Stock
Proface LT4000M Description Inventory status


Proface LT4000M Series HMI Manuals PDF Download:

  • LT4000M 3.5 in. Datasheet
  • LT4000M 5.7 in. Datasheet
  • LT-4201TM LT-4301TM Hardware Manual
  • LT-4201TM LT-4301TM Installation Guide
  • PFXLM4201TADDC Specifications

  • FAQ:

    Question: What is Proface LM4201TADDC PFXLM4201TADDC Touch Screen Panel Glass Protective Film HMI parts price?

    Answer: Submit a fast quote, send VICPAS an email for best price.


    Question: LM4201TADDC PFXLM4201TADDC USB Cable Clamp Removal

    Answer:
    (1) Pull out the USB cover from the USB holder by pressing down the tab on the USB cover.
    LM4201TADDC PFXLM4201TADDC USB Cable Clamp Removal
    (2) Insert the tip of a flat-blade screwdriver into the hole on the bottom of the USB holder and raise the handle so that the USB holder detaches from the USB host interface.
    LM4201TADDC PFXLM4201TADDC USB Cable Clamp Removal
