Model
2711P-K6C20D8

Item specifics

Brand
Allen Bradley
Warranty
365 Days
Product Line
PanelView Plus 6
Size
5.7 Inch
Supply
PanelView Plus 6 Membrane Keypad Switch
Parts
2711P-K6C20D8 Membrane Keypad Switch

Review

Description

2711P-K6C20D8 PanelView Plus 6 Membrane Keyboard Keypad Switch LCD Display Plastic Case Cover Repair Replacement

Order each part separately is available

2711P-K6C20D8 PanelView Plus 6 Membrane Keyboard Keypad Switch LCD Display Plastic Case Cover Bracket Gasket Label Sticker Protection Board and Mounting Levers Repair Replacement

The Allen-Bradley 2711P-K6C20D8 PanelView Plus 6 operator interface device is used for monitoring many automation applications. It offers convenient control and interfaces through its stainless steel numerical, navigational, and functional (F1-F10) keys, with an actuation of 1 million presses, and a shock resistance of 340G. Machines statuses and modes are viewed graphically through 5.7-inch, color active matrix, thin-film-transistor display screen, with a 320 x 240-pixel display resolution, and 4.37in x 3.3in display dimensions. The 2711P-K6C20D8 display brightness is 300 cd/m2 Nits and comes with a non-replaceable CCFL backlight with 50,000 hours of standby time. It also comes with 64MB of non-expandable user memory for the long-term storage of user applications, and 64MB of RAM for processing of applications.


The 2711P-K6C20D8 comes with the NEC VR5532A MIPS processor, with a processing speed of 350 MHz, and it has the FactoryTalk View ME Station (runtime) software and it can support any FactoryTalk View ME applications (version 3.20-5.10). It has an internal battery-backed real-time clock with ±2 minutes per month of variation, and it supports 256MB compact flash external memory. It can communicate through the 10/100Mbps Ethernet, and an RS-232 base configured communication ports, and it can utilize the compatible DH-485 communication module for wider network capability. It has a power source with an input rating of 24V DC nom (18-30V DC), and a maximum power consumption of 25W at 1A, 24V DC. The 2711P-K6C20D8 has an operating temperature range of 0-55 °C (32-131 °F), at 5-95% humidity without condensation, and it is built to resist an operational vibration of 2G at 57-500 Hz and a shock of 15G. The 2711P-K6C20D8’s net weight is 930g (2.05lb), and it has dimensions of 167mm x 266mm x 98mm (6.58 x 10.47in x 3.86in).


VICPAS supply Panelview Standard 6 2711P-K6C20D8 membrane keypad switch, Bracket, Label, Plastic Cover Body, LCD Screen, Protection Board, Gasket, Sticker and Mounting Levers for repair replacement, make the HMI running. We provide a 1-year warranty of the most product, which include most of touch screen panel, membrane keypad, LCD display and protective case shell housing.





Specifications:

The table below describes the parameters of the 2711P-K6C20D8 PanelView Plus 6 membrane keyboard keypad switch.

Part Number: 2711P-K6C20D8
Product Line: PanelView Plus 6
Screen diagonal 14 in
Warranty: 365 Days Warranty
Input Power: 24 VDC
Software: Panelbuilder 32
Operating Temp: 32-131 F (0-55 C)
Input Type: Keypad
Communication: Remote I/O and RS-232 Printer Port
Display Dimensions: 10.0 x 7.5 in (255 x 191 mm)


Related PanelView Plus 6 Series Part No. :

PanelView Plus 6 HMI Description Inventory status
2711P-K4C5A8 Allen Bradley Panel Plus 6 Membrane Keypad In Stock
2711P-K4C5D8 Allen Bradley Panel View Plus 6 Keypad Repalcement In Stock
2711P-K4C20A8 PanelView Plus 6 Membrane Switch Replacement Kit In Stock
2711P-K4C20D8 PanelView Plus 6 Membrane Keyboard Keypad Repair In Stock
2711P-K4M5A8 PanelView Plus 6 Membrane Keypad Switch Repair Kit Available Now
2711P-K4M5D8 Allen Bradley PanelView Plus 6 Operator Panel Keypad Replacement In Stock
2711P-K4M20A8 PanelView Plus 6 Operator Keyboard Replacement Available Now
2711P-K4M20D8 Allen Bradley Panel View Plus 6 Keyboard Membrane In Stock
2711P-K6C5A8 PanelView Plus 6 Membrane Keyboard Repair Kit Plastic Shell LCD In Stock
2711P-K6C5A9 PanelView Plus 6 Membrane Keyboard Keypad LCD Display Case Available Now
2711P-K6C5D8 Allen Bradley Panel View Plus 6 Keypad Plastic Case LCD Display Screen In Stock
2711P-K6C5D9 PanelView Plus 6 Switch Membrane HMI Case LCD Display Screen In Stock
2711P-K6C20A8 PanelView Plus 6 Touch Screen Keypad Front Cover LCD Display Panel Available Now
2711P-K6C20A9 Allen Bradley PanelView Plus 6 Membrane Keyboard Plastic Case LCD Screen In Stock
2711P-K6C20D8 PanelView Plus 6 Membrane Keyboard Keypad Housing LCD Display Screen Available Now
2711P-K6C20D9 Allen Bradley Panel View Plus 6 Operator Panel Keypad Front Cover LCD In Stock
2711P-K6M5A8 Allen Bradley Panel View Plus 6 Keypad Plastic Shell LCD Screen In Stock
2711P-K6M5D PanelView Plus 6 Membrane Switch Plastic Case LCD Display In Stock
2711P-K6M5D8 PanelView Plus 6 Switch Membrane HMI Case LCD Display Screen In Stock

FAQ:

Question: What are the status indicators for 2711P-K6C20D8?

Answer: 2711P-K6C20D8 has two indicators: a green COMM indicator and a red fault indicator.


Question: What is the voltage rating of the 2711P-K6C20D8 Allen Bradley ?

Answer: The 2711P-K6C20D8 has a voltage rating of 85 to 264 Volts AC.


Question: Does the 2711P-K6C20D8 Panelview Plus 6 have a replacement backlight?

Answer: Yes, the 2711P-K6C20D8 has a replacement backlight, although different series have different replacement parts. 2711P-K6C20D8 has the following replacement part number: 2711-NL4, Series B: 2711-NL6, Series C: 2711-NL7, Series D, and Series E: 2711NL9, and for Series F: 2711-NL10.


Question: How many touch cells does 2711P-K6C20D8 have?

Answer: 2711P-K6C20D8 has 384 touch cells in 24 columns by 16 rows. The touch cell size is 33 x 37 pixels.


Question: What is the 2711P-K6C20D8 PanelView Plus 6 touch screen panel price?

Answer: Submit a fast quote, send VICPAS an email for best price.
