HMI Case Membrane Keyboard for 6FC5203-0AF00-0AA0
- Model
- 6FC5203-0AF00-0AA0 OP010
Item specifics
- Keypad Button Material
- Metal
- Membrane Material
- Plastic
- Application
- Industry Equipment
- Place of Origin
- China
Review
Description
6FC5203-0AF00-0AA0 Siemens SINUMERIK HMI OP010 OPERATOR PANEL Keypad Membrane and HMI Case Housing Repair Replacement
Order each part separately is available
General sequence of Siemens 6FC5 203-0AF00-0AA0 Membrane Keyboard HMI Case
1. Use the Program manager to select the desired program.
2. Select the desired program under "NC". If necessary, it must first be copied to "NC".
3. Press the "Select" softkey of 6FC52030AF000AA0. The program is selected for execution and automatically switched to the "Machine" operating area.
4. Press the "CYCLE START" key. The program of 6FC5203-0AF00-0AA0 Housing Terminal Keypad is started and executed.
Teaching in programs
• The "Teach-in" function of 6FC5203-0AF00-0AA0 Membrane Keyboard HMI Cover can be used to edit programs in the "AUTO" and "MDA" modes. You can create and modify simple traversing blocks.
• You traverse the axes manually to specific positions in order to implement simple machining sequences and make them reproducible. The positions you approach are applied.
• In "AUTO" teach-in mode, the selected program of 6FC5 203-0AF00-0AA0 Plastic Shell Membrane Keypad Switch is "taught".
• In "MDA" teach-in mode, you teach to the MDA buffer.
• External programs of 6FC5 203-0AF00-0AA0, which may have been rendered offline, can therefore be adjusted and modified according to need.
The defined user data of 6FC52030AF000AA0 Operator Panel Keypad Plastic Housing
• Data parameters(R parameters)
• Global user data(GUD)is valid in all programs of 6FC5 203-0AF00-0AA0
• Local user data (LUD)is valid in one program
• Program-global user data(PUD)is valid in one program and the called subroutines
• Channel-specific user data can be defined with a different value for each channel of 6FC52030AF000AA0 HMI Case Membrane Keypad
Specifications:
The table below describes the parameters of the 6FC5203-0AF00-0AA0 Siemens OP010 HMI Parts.
| Screen Diagonal: | 10.4 in TFT |
| Interface: | Front USB Interface |
| Attachment: | Tension Jacks |
| Warranty: | 6-Months Warranty |
| Power Supply: | Status LEDs |
| Resolution: | 640 x 480 Pixel |
| Part Number: | 6FC5203-0AF00-0AA0 |
| Degree of Protection: | IP65 |
| Depth: | Small Mounting Depth |
| Panel Cutout: | 450 x 290 mm |
Related Simatic OP010 Part No. :
| SINUMERIK OP010 Keypad | Description | Inventory status |
| 6FC5203-0AF00-0AA0 | Siemens SINUMERIK HMI OP010 Terminal Keypad HMI Case Repair | In Stock |
| 6FC5203-0AF00-0AA1 | Siemens OP010 Membrane Switch Housing Replacement | Available Now |
| 6FC5203-0AF00-0AA3 | Siemens SINUMERIK Plastic Case Operator Keyboard Repair | In Stock |
| 6FC5203-0AF01-0AA0 | Siemens OP010 Keypad Membrane HMI Cover Replacement | In Stock |
| 6FC5203-0AF11-1AA0 | Siemens OP010 HMI Case Membrane Keypad Switch Repair | Available Now |
| 6FC5203-0AF11-2AA0 | Siemens SINUMERIK Keyboard Membrane Housing Replacement | In Stock |
| 6FC5203-0AF12-0AA1 | Siemens SINUMERIK OP010 Terminal Keypad Plastic Cover Repair | Available Now |
| 6FC5248-0AF00-0AA0 | Siemens OP010 Housing Switch Membrane Repair | Available Now |
| 6FC5248-0AF00-0AA2 | SINUMERIK OP010 Membrane Keypad Plastic Case Replacement | In Stock |
| Siemens OP010 Part No. | Description | Inventory status |
Siemens OP010 series HMI Manuals PDF Download:
FAQ:
Question: Are there lists for tool management for Siemens SIMATIC 6FC5 203-0AF00-0AA0 OP010?
Answer: Yes. HMI sl provides the "Tool list", "Tool wear list", "OEM tools" and "Magazine" windows for managing your tools. Tool management supports several magazines. The active magazine is displayed in the title line of each list. The various lists may have been changed by the machine manufacturer, in comparison to the following description.
Question: Where is the Storage for programs of Siemens 6FC52030AF000AA0?
Answer: The Possible storage locations of 6FC5203-0AF00-0AA0 are NC, Local drive, Network drives or USB drives.
