Model
1201-680 BTTI 0516-X123 03-TW

Item specifics

Brand
TTI Touch Screen
Warranty
365 Days
Supply
TTI HMI Touchscreen Panel
Touch Screen Type
Resistance touch screen
Part Number
1201-680 BTTI 0516-X123 03-TW

Review

Description

1201-680 B TTI 0516-X123 03-TW MMI Touch Glass Replacement Repair

Order each part separately is available

1201-680 B TTI 0516-X123 03-TW Touch Screen Panel Replacement
1201-680 B TTI 0516-X123 03-TW Touch Screen Panel Replacement

Please pay attention for the matter as stated below at mounting design of 1201-680 BTTI 0516-X123 03-TW touch panel & enclosure:
1. Enclosure support to fix 1201-680 BTTI 0516-X123 03-TW touch panel glass must be out of view (transparent) area. (Do not design enclosure presses the view area to protect from miss input).
2. Enclosure edge must be between view area & guaranteed active area. (Enclosure edge must not touch with view area).
3. We recommend the material of support to fix 1201-680 BTTI 0516-X123 03-TW touch screen panel is an elastic material.
4. Do not bond top surface (film) of 1201-680 BTTI 0516-X123 03-TW panel glass with enclosure.
5. The corner parts (fig.*) have conductivity. Do not touch any metal part after mounting.
6. Special design is required for water resistance use.
7. Cleaning 1201-680 BTTI 0516-X123 03-TW Touch Digitizer by Air gun, pressure 2kg/cm2 below is suggested. This is preventing FPC to peel off when air is blowing to FPC from 1201-680 BTTI 0516-X123 03-TW touch screen monitor side.
8. The mounting structure must have a reserved space for the FPC tail and never touch or squeeze the FPC by case or other components preventing FPC to peel off. Assembly space is recommended at least 4mm.


VICPAS supply 1201-680 B TTI 0516-X123 03-TW touch panel glass with 365 days warranty and support Urgent Worldwide Shipping.





Specifications:

The table below describes the parameters of the 1201-680 B TTI 0516-X123 03-TW TTI HMI Touch Membrane.

Part Number: 1201-680 B 0516-X123 03-TW
Warranty: 1-Year Warranty
Number of Touches: Single
Storage Temperature: -20˚C to 70˚C
Operating Temperature: -5˚C to 60˚C
Product Line: TTI Touch Panel
Tail Options: FPC tail
Response time: ≦ 30ms
Storage Humidity: 10% to 90% RH
Operating Humidity: 20% to 85% RH


Related TTI Touch Screen HMI Part No. :

TTI Touch Screen Description Inventory status
0516-X123 03-TW TTI Touch Screen Glass Replacement In Stock
1201-120R B TTI 1201-X111 07-NA 1201-X111/04 NA TTI Touch Screen Panel Replacement Available Now
1201-680 B TTI TTI HMI Touchscreen Repair Part In Stock
1201-800 A TTI 1301-X911 01 TTI HMI Touch Screen Glass Repair Available Now
1201-X151 A TTI 1201-X151 02 TTI Touch Screen Panel Replacement In Stock
1201-X231 03 1305-524 C TTI TTI Touch Membrane Replacement In Stock
1301-010 02 TTI HMI Touch Glass Replacement In Stock
1301-X161 A TTI 1301-161 D TTI TTI HMI Panel Glass Replacement Available Now
1301-840 A TTI 1201-X131-01 T010-1201-X131-01 TTI Touch Digitizer Glass Repair Available Now
1301-910 BTTI 1301-X911 01 TTI Touch Screen Monitor Repair In Stock
1301-X161 1301-161 B TTI TTI HMI Touch Panel Replacement Available Now
1301-X991 02-NA TTI HMI Touchscreen Repair Part In Stock
TTI Touch Panel Description Inventory status

FAQ:

Question: What is the dimension of the 1201-680 B TTI Touch Screen Monitor?

Answer:The 1201-680 B TTI touchscreen panel is 10.1 inch.


Question: What is the 1201-680 B TTI 0516-X123 03-TW HMI Touch Screen Panel Glass price?

Answer: Submit a fast quote, send VICPAS an email for best price.
