6AU1350-2AH23-1BE1 Siemens SINUMERIK HMI OP012T OPERATOR PANEL Touch Digitizer Glass Terminal Keypad and Plastic Shell Cover Repair Replacement

Order each part separately is available

6AU13502AH231BE1 Siemens SINUMERIK HMI OP012T OPERATOR PANEL Membrane Switch and Touch Digitizer Glass Plastic Case Cover Repair Replacement


Direct control key module of Siemens 6AU1350-2AH23-1BE1 Touch Screen Display Terminal Keypad
The task of the direct control key module (DKM)is to directly transfer the operating signals for the two rows of keys on the sides of 6AU1 350-2AH23-1BE1 operator panel front to SIMATIC without diversion through intermediate firmware. The signal-to-key assignments are shown in the table and figure in section: "Interfaces"-"Operator panel front."
The DKM can be combined with operator panel fronts of type OP 012, OP 012T, OP 015A or TP 015A.
The DKM of 6AU13502AH231BE1 HMI Panel Glass Terminal Keypad converts the key signals to the PROFIBUS DP protocol by means of the ASIC LSPM2(PROFIBUS DIN 19245 Part 1,12 MBaud).
Power is supplied via the 6AU1350-2AH23-1BE1 operator panel front. The PROFIBUS is completely isolated from the DKM/operator panel front by means of an opto-coupler and DC/DC converter. The DKM operates as a slave on PROFIBUS. The address can be set between 1 and 99 using rotary switches. Two bytes of data are transferred.
In SIMATIC, the keys of Siemens 6AU1 350-2AH23-1BE1 Touch Digitizer Membrane Keyboard are handled as if they were 16 ordinary digital inputs.

Card reader with USB interface of 6AU13502AH231BE1
• The SINUMERIK card reader is intended for archiving and exchanging user data.
• The card reader of 6AU1350-2AH23-1BE1 Switch Membrane Touch Panel is connected via the USB interface. It can be installed in a front panel. This makes data exchange possible without opening the control cabinet.
• The card reader can be booted.
• All cards of 6AU1 350-2AH23-1BE1 Operator Keyboard Touch Membrane can be inserted and removed during operation.




Specifications:

The table below describes the parameters of the 6AU1 350-2AH23-1BE1 Siemens OP012T HMI Parts.

Attachment: Tension Jacks
Protection: IP 65
Flat Screen: 12.1 in TFT
Product Line: Siemens OP012T
Softkeys: 2 x 8 Horizontal Rows
Mounting Depth: Slight
Resolution: 800 x 600 Pixels
Part Number: 6AU1350-2AH23-1BE1
Height Units: 7 HU
Power Supply: Status LEDs


Related Simatic OP012T Part No. :

SINUMERIK OP012T Keypad Description Inventory status
6AU1350-2AH23-1BE1 Siemens SINUMERIK HMI OP012T Terminal Keypad Repair In Stock
6FC5203-0AF02-0AA0 Siemens OP012 Membrane Switch Replacement Available Now
6FC5203-0AF02-0AA1 Siemens SINUMERIK Operator Keyboard Repair In Stock
6FC5203-0AF02-0AA2 Siemens SINUMERIK HMI OP012 Keypad Membrane Replacement In Stock
6FC5203-0AF06-1AA0 Siemens OP012T Membrane Keypad Switch Repair Available Now
6FC5203-0AF07-0AA0 Siemens SINUMERIK Keyboard Membrane Replacement In Stock
6FC5203-0AF52-0AA0 Siemens SINUMERIK HMI OP012 Terminal Keypad Repair Available Now
6FC5210-0DF22-0AA0 Siemens OP012 Switch Membrane Repair Available Now
6FC5248-0AF02-0AA0 Siemens SINUMERIK HMI OP012 Membrane Keypad Replacement In Stock
6FC5248-0AF02-0AA2 Siemens SINUMERIK HMI OP012 Membrane Keypad Replacement In Stock
Siemens OP012T Part No. Description Inventory status


Siemens OP012T series HMI Manuals PDF Download:


FAQ:

Question: What should I pay attention to screen saver of 6AU1 350-2AH23-1BE1?

Answer: The ribbon cable for the 6AU13502AH231BE1 operator panel front is inserted through the cut-out in the casing. Here, the switching states of the vertical direct control keys can be picked up without intermediate firmware. These signals can be evaluated in the direct control key module. Direct control key interface X11 on the keyboard controller for the operator panel front: per DIN 41651, plug connector, cable length max.0.5 m.


Question: How to mount 6AU13502AH231BE1 on the mounting wall?

Answer:
1. Insert the OP 012T 6AU1350-2AH23-1BE1(with direct control key module if required)in the panel cutout from the front.
2. Fix the operator panel front in the panel cutout from the rear using the six tension jacks by tightening the setscrews (torque 0.4-0.5 Nm).
