Model
PP880R 3BSE069295R1

Item specifics

Warranty
365 Days
Product Line
HMI Panel 800
Types
Front Overlay Touch Panel Glass
Shipping
2-3 workdays
Size
7 inches
Part Number
PP880R 3BSE069295R1

Review

Description

HMI Panel 800 PP880R 3BSE069295R1 Protective Film Resistive Touch Panel Repair Replacement

Order each part separately is available

HMI PP880R 3BSE069295R1 Front Overlay Touch Panel Glass Replacement

VICPAS supply HMI Panel 800 PP880R 3BSE069295R1 Touch Screen Panel and Front Overlay with 365 Days warranty and support Urgent Worldwide Shipping.


The PP880R 3BSE069295R1 Protective Film Touch Screen Monitor operator panel is designed for stationary installation on a planar surface, where the following conditions are fulfilled:
– no high explosive risks
– no strong magnetic fields
– no direct sunlight
– no large, sudden temperature changes
• Install the PP880R 3BSE069295R1 Touch Digitizer Glass Front Film operator panel according to the accompanying installation instructions.
• Ground the operator panel according to the accompanying installation instructions.
• Only qualified personnel may install the operator panel.
• Separate the high voltage, signal and supply cables.
• Make sure that the voltage and polarity of the power source is correct before connecting the operator panel to the power outlet.
• Peripheral equipment must be appropriate for the application and location.
• In a Zone 2 environment, this equipment shall be installed in an enclosure that provides a degree of protection not less than IP 54 or greater than IP 65 in accordance with IEC/EN 600079-0. The IP rating of the equipment is limited to the IP rating of the enclosure it is to be installed into.
• In a Zone 22 environment, this equipment shall be installed in an enclosure that provides a degree of protection not less than IP 64 or greater than IP 65 in accordance with IEC/EN 600079-0. The IP rating of the equipment is limited to the IP rating of the enclosure it is to be installed into.





Specifications:

The table below describes the parameters of the PP880R 3BSE069295R1 Front Overlay Touch Membrane HMI Panel 800 Machine.

Part Number: PP880R 3BSE069295R1
NEMA: 4x indoor use only
Active Area Of Display: 152.4 × 91.4 mm
Operating Temperature: -10 °C to +60 °C
Touch Material: Polyester on glass
Display Resolution: 800 × 480 pixels
Diagonal (inches): 7"
Display Type: TFT-LCD
Part Type: New
Warranty: 365 Days


Related HMI Panel 800 Terminals Part No. :

HMI Panel 800 Description Inventory status
PP885 3BSE069276R1 HMI Panel 800 PP885 Front Overlay Touch Membrane In Stock
PP885A 3BSE042238R2 Panel 800 Series PP885A Touch Glass Front Overlay Repair In Stock
PP885H 3BSE069281R1 Panel 800 Series PP885H Touch Digitizer Glass Overlay Repair Available Now
PP885M 3BSE069280R1 Panel 800 PP885M HMI Panel Glass Protective Film Available Now
PP885R 3BSE069296R1 Panel 800 Series PP885R Touch Screen Monitor Front Overlay In Stock
PP886 3BSE092980R1 Panel 800 Series PP886 Front Overlay MMI Touch Screen Replacement In Stock
PP886H 3BSE069297R1 Panel 800 Series PP886H HMI Touch Screen Protective Film Available Now
PP886M 3BSE092984R1 Panel 800 Series PP886M Protective Film Touchscreen Repair In Stock
PP886R 3BSE092985R12 Panel 800 Series PP886R HMI Protective Film Touch Screen Glass Available Now
PP887H 3BSE092986R1 Panel 800 Series PP887H Front Overlay Touch Screen Panel Repair In Stock
PP887S 3BSE092987R1 Panel 800 Series PP887S Touch Screen Protective Film Replacement In Stock
PP893 3BSE069277R1 Panel 800 Series PP893 Touch Screen Monitor Front Overlay Replacement In Stock
PP895 3BSE092981R1 Panel 800 Series PP895 Front Overlay Touch Digitizer Glass Available Now
PP896 3BSE069278R1 Panel 800 PP896 Protective Film HMI Panel Glass Replacement In Stock
Panel 800 Repair Description Inventory status


Systeme Lauer HMI Manuals PDF Download:

  • Panel 800 Version 6 PP885 Hardware and Installation
  • Panel 800 Version 6 PP874M Hardware and Installation
  • Panel 800 Version 6 PP885M Hardware and Installation
  • Panel 800 Version 6 PP885H Hardware and Installation
  • Panel 800 Version 6 PP880R Hardware and Installation
  • Panel 800 Version 6 PP885R Hardware and Installation
  • Panel 800 Version 6 PP886H Hardware and Installation
  • Compact Product Suite Panel 800 Version 6 PP885 Hardware and Installation

  • FAQ:

    Question: What is the price of PP880R 3BSE069295R1 Touch Panel Glass and Protective Film?

    Answer: Submit a fast quote, send VICPAS an email for best price.


    Question: What is the size of the PP880R 3BSE069295R1 Resistive Touch Screen and Front Overlay?

    Answer: The PP880R 3BSE069295R1 Front Overlay Touch Digitizer Glass is 7-inch.


    Question: How to install the PP880R 3BSE069295R1 Touch Screen Monitor Protective Film operator terminal?

    Answer:

    1. Unpack and check the delivery. If damage is found, notify the supplier.
    PP880R 3BSE069295R1 Touch Panel Front Overlay Repair
    2. Disconnect the PP880R 3BSE069295R1 operator panel from the power supply.
    3. Remove the plastic cover from the expansion port.
    PP880R 3BSE069295R1 Front Overlay Touch Panel Glass Replacement
    4. Secure the expansion module in position, using the provided screws.
    5. Connect the PP880R 3BSE069295R1 Front Overlay Touch Digitizer Glass operator panel to the power supply.
