6AG1322-5HF00-4AB0 Siemens SIMATIC S7-300 Module Housing Repair Replacement


6AG1322-5HF00-4AB0 Siemens SIMATIC S7-300 SM 322 digital output modules Plastic Shell Repair Replacement

S7-300 6AG13225HF004AB0 SM 322 digital output modules HMI Case systems are intended for stationary use in locations protected against the weather. The operating conditions surpass the requirements of DIN IEC 60721-3-3.
 Class 3M3 (mechanical requirements)
 Class 3K3 (climatic requirements)


Programmable digital IO module SM 322; DI 8/DO 8 x DC 24 V/0.5 A (6AG1322-5HF00-4AB0 Plastic Shell) Properties
Properties of SM 322; DI 8/DO 8 x DC 24 V/0.5 A:
• 8 digital inputs and 8 individually configurable inputs or outputs, isolated in groups of 16
• Rated input voltage 24 V DC
• Inputs suitable for switches and 2-/3-/4-wire proximity switches (BEROs)
• Output current 0.5 A
• Rated load voltage 24 V DC
• Outputs capable of driving solenoid valves, DC contactors and indicator lights
• Dynamic change of parameters in RUN (CiR-compatible), separately at each channel.
• Readback of outputs.


VICPAS supply 6AG1322-5HF00-4AB0 Siemens S7 300 Simatic Module Plastic Case Cover Replacement Part. All of them with VICPAS 365 days warranty and support Urgent Worldwide Shipping.





Specifications:

The table below describes the parameters of the 6AG1322-5HF00-4AB0 Siemens SIMATIC SM 322 digital output modules Case Parts.

Part Number : 6AG1322-5HF00-4AB0
Atmospheric pressure: 1080 to 660 hPa
Temperature: –40 °C to +70°C
Warranty: 365 days Warranty
Product Line: Siemens Simatic S7-300
Dimensions W x H x D (mm): 40 x 120.4 x 110.8
Safety isolation: SELV circuit
Power consumption: 57 W
Power loss: Typ. 9 W
Efficiency: 84 %


Related Siemens Simatic S7-300 Part No. :

Siemens Simatic S7-300 Description Inventory status
6AG1322-1FH00-7AA0 Siemens S7-300 SM 322 Plastic Case Replacement In Stock
6AG1322-1HF10-2AA0 SIMATIC S7 300 SM322 HMI Enclosure Replacement In Stock
6AG1322-1HH01-2AA0 SIMATIC S7 300 Plastic Case SM 322 Replacement Available Now
6AG1322-5FF00-4AB0 Siemens S7-300 SM 322 Housing Repair Replacement Available Now
6AG1322-5HF00-4AB0 Siemens S7-300 Plastic Shell SM 322 Repair In Stock
6AG1322-8BF00-2AB0 SIMATIC S7 300 HMI Case SM 322 Replacement Available Now
6AG1323-1BH01-2AA0 Siemens S7-300 SM 323 Housing Replacement In Stock
