TPI#1405-001 Rev D Trimble Touch Screen Monitor
- Model
- TPI#1405-001 Rev D
Item specifics
- Brand
- Trimble
- Warranty
- 365 Days
- Product Line
- Trimble series
- Supply
- TPI#1405-001 Rev D Touch Screen Panel Repair part
- Size
- 8 inch
- Model
- TPI#1405-001 Rev D
Review
Description
Trimble series TPI#1405-001 Rev D Touch Screen Tablet Repair Kit.
The Trimble® TPI#1405-001 Rev D display is an in-cab TPI#1405-001 Rev D touchscreen display that provides affordable guidance, steering and precision agriculture functionality. The TPI#1405-001 Rev D display Touch screen panel glass includes a built-in GPS receiver that you can upgrade to receive GLONASS satellite signals. The TPI#1405-001 Rev D display Touch Panel is used in agricultural applications to maximize efficiency in activities such as planting, spraying, spreading and strip tilling.
VICPAS supply TPI#1405-001 Rev D Trimble Touchscreen glass with 365 Days warranty and support Urgent Worldwide Shipping.
Specifications:
The table below describes the parameters of the TPI#1405-001 Rev D Trimble HMI Panel Glass.
| Part Number: | TPI#1405-001 Rev D |
| Screen diagonal: | 8 in |
| Warranty: | 365 Days |
| Product Line: | Trimble Series |
| Input Power: | +24 VDC +/-20% |
| Resolution: | 1280 x 800 dot |
| Storage Temperature: | -20°C to 60°C |
| Display Size: | STN |
Related Trimble Series Part No. :
| Trimble HMI | Description | Inventory status |
| TPI#1389-001 Rev C | Trimble HMI Touch Screen Monitor | In Stock |
| TPI#1389-002 Rev C | Touch Screen Glass Trimble HMI Series | Available Now |
| TPI#1395-001 Rev C | Trimble Touch Digitizer Glass Repair | In Stock |
| TPI#1405-001 Rev D | Trimble Touch Screen Panel Replacement | In Stock |
| Trimble HMI | Description | Inventory status |
Trimble Series HMI Manuals PDF Download:
FAQ:
Question:How to install the Trimble TPI#1405-001 Rev D display?
Answer:
1. Use the supplied screws to firmly attach the diamond-shaped mounting plate to the display:
2. Attach the RAM mount to the ball on the diamond-shaped mounting plate:
3. Select a position in the cab for the display. Hold the display in the selected location and check that it is easily accessible form the driver’s seat.
4. Use the provided bolts to attach the bar mount to the cab.
5. Attach the other end of the RAM mount to the ball on the bar mount and then tighten the screw.
6. Connect the display to a power source.
Question: What is the dimension of TPI#1405-001 Rev D Trimble Touch Panel Glass?
Answer:The dimension of TPI#1405-001 Rev D Trimble HMI touch membrane is 8 inch.
Common misspellings:
TPI#1405-01TP#1405-001
TPI#1405-010
TPI#l405-001
TPI#1405-0011
