Membrane switch for XBTGK2120 membrane keypad keyboard

Group Magelis XBT GT/GTW/GK
Min. Order 1 piece
Terms of Payment Western Union, MoneyGram, T/T, Paypal, PayPal, T/T ,Credit Card, Western Union
Update Time 2019-05-22
Item specifics
Warranty180 days VICPAS Warranty
Membrane MaterialPlastic
ApplicationIndustry Equipment
Part No.Scheider XBTGK2120 XBT GK 2120

Magelis XBTGK2120 Membrane Keypad with Touchscreen for replacement

The XBTGK2120 switch keypad is Schneider Magelis XBT GK series advanced touchscreen panel with keyboard. It is small keypad panel and easy to use. This type product make for PET(polyester) and PC(polycarbonate), which is strong manufacturability and durability. The life cycle of keys is up to 5 million times.

The Magelis XBTGK2120 control keypad includes different buttons, each representing different functions that can make automation equipment to achieve different operations and operations. The conductive structure of the keyboard is very complex. Generally, the conductive material is silver or copper.

The XBTGK2120 HMI also has the innovative Point-Access feature which allows users to review and monitor data files. These files are compiled from the SLC and PLC controllers that are in use. Data blocks can also be modified in the XBTGK2120 thanks to the DTAM Micro feature. Like all other Schneider devices on the market, the XBTH012010 keypad switch also comes with a 180-days warranty.

 Contact VICPAS for More Information


The table below describes the parameters of the XBTGK2120 keypad switch touchscreen.

Part Number : XBTGK2120
Product Line: Magelis XBT GK Series
Touchscreen Size: 5.7 in.
Warranty: 180 days Warranty
Touch Technology: Keyboard
Rated Voltage: DC 5V 1mA
Operating Temp.: -10℃~+80℃
Storage Temp.: -20℃~+70℃
lineation test: ≥1.000.000 times
Input Type: ≥100.000 times

PDF Download:

  • Magelis XBTGK2120 User Manual Product datasheet PDF

  • Magelis XBTGT Series Part No.

    Magelis XBT GK Description Inventory status
    XBTGK2120 advanced touchscreen panel with keyboard- 5.7''In Stock
    XBTGK2330 advanced touchscreen panel with keypad-5.7''In Stock
    XBTGK5330 advanced touchpanel with keyboard- 10.4''In Stock
    Schneider XBT GK Description Inventory status


    Question: Is the internal backlight replaceable?

    Answer: No, the internal backlight of XBTGK2120 is not replaceable.

    Question: Is the battery replaceable?

    Answer: No, the battery of XBTGK2120 is not replaceable.

    Question: What is the price of XBTGK2120 HMI Parts?

    Answer: Submit a quote request, send us an email for our best price.
