ATS22D17Q ATS22D17S6 ATS22D17S6U Keyboard Membrane Repair
ATS22D17Q ATS22D17S6 ATS22D17S6U Keyboard Membrane Repair
Model
ATS22D17Q ATS22D17S6 ATS22D17S6U

Item specifics

Brand
Schneider
Warranty
365 Days
Supply
ATS22D17Q ATS22D17S6 ATS22D17S6U Membrane Switch
Range of product
Schneider ATS22

Review

Description

Schneider Altistart 22 ATS22D17Q ATS22D17S6 ATS22D17S6U Operator Panel Keypad Repair Kit


Schneider HMI ATS22D17Q ATS22D17S6 ATS22D17S6U Switch Membrane Repair Kit

As the exclusive human-machine interface for Schneider Altistart 22 soft starters, this ATS22D17Q ATS22D17S6 ATS22D17S6U Keypad Membrane Switch delivers precise control and reliable performance, perfectly supporting soft start/stop operations across construction, infrastructure, and industrial sectors.


Cost-Efficiency & Performance Synergy
• Easy Installation: Plug-and-play design, no firmware programming required—cuts wiring and setup time.
• Protects Power Distribution: Reduces current spikes and voltage drops during motor startup via soft start control.
• Lowers Operating Costs: Minimizes mechanical wear on equipment, reducing maintenance frequency.


Reliable & Durable
• 100% compatible with Altistart 22 soft starter; designed for long keystroke life to withstand frequent operations.
• Excellent EMC performance for stable operation in harsh industrial environments (dust, vibration, electromagnetic interference).
• Intuitive interface with clear start/stop buttons; real-time status and fault monitoring for quick operation.


VICPAS supplies replacement Schneider ATS22D17Q ATS22D17S6 ATS22D17S6U Terminal Keypads with a 12-month warranty and offers urgent worldwide shipping.





Specifications:

The table below describes the parameters of the Altistart 22 ATS22D17Q ATS22D17S6 ATS22D17S6U Membrane Keyboard Keypad.

Brand: Schneider
Operating Temp.: -10 °C to 40 °C, without derating
Storage Temp.: -25 °C to 70 °C
Relative Humidity: 0-95% non-condensing
Range Compatibility: Altistart 22
Supply Frequency: 50...60 Hz - 10...10 %
Warranty: 365 Days Warranty
Phase: 3 phase


Related Schneider Altistart 22 Series Part No. :

Schneider Altistart 22 Description Inventory status
Schneider ATS22 Description Inventory status


Schneider ATS22 HMI Manuals PDF Download:

  • Altistart 22 Soft Start - Soft Stop Unit User Manual
  • Altistart 22 Soft Start - Soft Stop Units Catalog

  • FAQ:

    Question: What are the common symptoms of a faulty keypad on Altistart 22 drives?

    Answer: Typical signs include unresponsive buttons, inconsistent input response, display not showing feedback, or inability to start/stop the motor via keypad. In such cases, replacing the keypad often resolves the issue without replacing the entire drive.


    Question: Are there any special applications for the ATS 22 soft start/soft stop device?

    Answer: ATS 22 soft start/soft stop units can be used for applications outside the standard characteristics, but this may involve derating by at least one power rating.
    Examples of applications outside the standard characteristics:
    ⦁ Greater number of starts
    ⦁ Motor thermal protection higher than class 10
    ⦁ Excess current required on starting
    ⦁ Certain ambient temperatures:
    For ambient temperatures between + 40 °C/+ 104 °F and + 60 °C/+ 140 °F, derate the nominal current of the Altistart by 2.2% for each additional degree.
    ⦁ Certain altitudes:
    For altitudes between 1,000 m/3,280 .83 ft and 2,000 m/6,561 .66 ft, derate the nominal current of the Altistart by 2% for each additional 100 m/328 .08 ft.


    Common misspellings:

    ATS22D117Q ATS22D17S6 ATS22D17S6U
    ATS22D17Q ATS2D17S6 ATS22D17S6U
    ATS22D17Q ATS22D17S6 ATS22D71S6U
    ATS22D17Q ATS22O17S6 ATS22D17S6U
    ATS22D1TQ ATS22D17S6 ATS22D1756U
