Model
Touch Anzeigeeinheit TAE1922-K

Item specifics

Touch screen tapes
Resistance touch screen
Brand
Sigmatek
Product Line
Touch Anzeigeeinheit Series Control Panel
Size
19 inch
Parts
Touch Screen Panel Glass Repair
Model
Sigmatek Touch Anzeigeeinheit TAE1922-K
Warranty
365 Days

Review

Description

SIGMATEK Touch Anzeigeeinheit TAE1922-K Touch Screen Panel Glass Protective Film Repair

Order each part separately is available

SIGMATEK Touch Anzeigeeinheit TAE1922-K Touch Screen Panel Glass Front Overlay Repair Replacement


The following clearance is required for the Sigmatek TAE 1922-K Protective Film Touch Digitizer Glass Terminal cover: Rear side, left and right 5 cm. Above and below 10 cm. A mounting position of 60° to 120° is also required. The TAE1922-K Touchscreen Panel Front Overlay terminal must be connected to earth through the mounting on control cabinet or over the TAE1922-K Touch screen panel glass Film terminal provided. It is important to create a low-ohm earth connection, only then can error-free operation be guaranteed. The earth connection should have the maximum cross section and the largest electrical surface possible.


VICPAS supply SIGMATEK Touch Anzeigeeinheit TAE1922-K touchscreen panel with protective film overlay, all of them are brand new with 365 days VICPAS warranty. The Touch Anzeigeeinheit TAE1922-K Control Panel with EDGDE Technology combines control, operation and visualization in a single unit. Local as well as decentralized I/O systems can be connected over the bus and therefore not bound to a specific topology when constructing your system. The available interface connections can be programmed completely from the application.



Specifications:

The table below describes the parameters of the Sigmatek TAE 1922-K Front Overlay Touchscreen Panel.

Part Number : TAE1922-K
Product Line: Sigmatek TAE
Screen diagonal 15 / 19 in
Warranty: 365 Days Warranty
Input Power 24 VDC
Display Type: TFT color
Mounting position: Vertical
Input Type: Touchscreen
Serial interface Type: RS232
Storage -20 to 70°C


Related Sigmatek Panel Part No. :

Touch Anzeigeeinheit Description Inventory status
TAE 0811 Sigmatek Touch Anzeigeeinheit Touch Screen Repair In Stock
TAE 121 Sigmatek Touch Anzeigeeinheit Touchscreen Repair In Stock
TAE 151 Touch Anzeigeeinheit Sigmatek Touch Panel Replacement Available Now
TAE 1921 Touch Anzeigeeinheit Sigmatek HMI Touch Screen Glass Available Now
TAE 1921-K Sigmatek Touch Anzeigeeinheit Touch Screen Panel Repair In Stock
TAE 1922-K Sigmatek Touch Anzeigeeinheit Touch Membrane Repair In Stock
TAE 1931 SIGMATEK Touch Anzeigeeinheit HMI Touch Glass Repair In Stock
TAE 1941 Sigmatek Anzeigeeinheit Touch Digitizer Glass Repair Available Now
TTAE534 Sigmatek Touch Anzeigeeinheit HMI Panel Glass Replacement Available Now
SIGMATEK HMI Description Inventory status

SIGMATEK TAE1921 Control Panel Manuals PDF Download:

  • Sigmatek TAE1921 Controller User Manual
  • Sigmatek TAE 1921 HMI Datasheet

  • FAQ:

    Question:How to exchange the Sigmatek TAE1922-K Battery?

    Answer:
    1. Disconnect the power to the TAE1922-K.
    2. Open the locking screws on the back f the terminal with a PH-1 screwdriver:
    How to exchange the Sigmatek TAE1922-K Battery?
    3. Lift rear panel of the terminal:
    For HW version 1.x:
    How to exchange the Sigmatek TAE1922-K Battery?
    4. Using the strap, remove the battery the holder (see arrow).
    5. Insert the new battery with the correct polarity and close the terminal.
    (+ Pole toward the backside)
    From HW version 2.x:
    How to exchange the Sigmatek TAE1922-K Battery?
    4. Using the strap, remove the battery from the holder (see arrow).
    5. Place the new battery in the holder with the correct polarity (+ Pole toward the frontside) and replace the cover.

    Question:What is the price of SIGMATEK TAE 1922-K Front Overlay Touch Screen Monitor?

    Answer: Submit a quote request, send us an email for our best price.
