6AG1643-0AA01-4AX0 Siemens Touch Panel TP277 Touchscreen
- Model
- 6AG1643-0AA01-4AX0
Item specifics
- Warranty
- 365 Days
- Brand
- Siemens
- Product Line
- TP277
- Supply
- Siemens TP277 HMI Touch Panel and Protecitve film
- Size
- 5.7 inch
- model
- 6AG1643-0AA01-4AX0
Review
Description
6AG1643-0AA01-4AX0 Siemens SIMATIC HMI TP277 6 Touch Screen Panel, Overlay, Case Gasket, LCD Gasket, Power Supply Connector, Plastic Cover Body, Mounting Clips, Screws and LCD Display Repair Replacement
Order each part separately is available
6AG1643-0AA01-4AX0 SIPLUS HMI TP 277 6"Touch for medial exposure based on 6AV6643-0AA01-1AX0
The HMI devices TP 277 and OP 277 represent a further stage of development of the HMI devices TP 270-6 and OP 270-6.
The HMI devices are based on the standard operating system Microsoft Windows CE.Compared with the Multi Panel MP 277, the TP 277 and the OP 277 offer an inexpensive scale option. The mounting options and the functional scope of the TP 277 and OP 277 are compatible with the HMI devices in the 270 series.
The TP 277 and OP 277 also have the following features:
• The HMI devices can be operated on PROFINET via the Ethernet port.
• The HMI devices feature a TFT screen with 256 colors.
• The use of projects with scripts and logs is supported.
VICPAS supply 6AG1643-0AA01-4AX0 Siemens TP277 touch panel, Overlay, Plastic Shell, Power Supply Connector, Case Gasket, LCD Gasket, Mounting Clips, Screws and LCD display. All of them with VICPAS 365 days warranty and support Urgent Worldwide Shipping.
Specifications:
The table below describes the parameters of the 6AG1643-0AA01-4AX0 Siemens TP277 HMI Parts.
| Part Number : | 6AG1643-0AA01-4AX0 |
| Size | 5.7 inch; |
| Display | TFT |
| Warranty: | 365 days Warranty |
| Product Line: | Siemens TP277 |
| Resolution: | 320 x 240; |
| Number of colors: | 256 |
| Control elements: | Touch screen |
| MTBF: | 60 000 h |
| PLC Connection: | SIMATIC S7-200 |
Related Simatic TP277 Part No. :
| Siemens TP277 | Description | Inventory status |
| 6AV6643-0AA01-1AX1 | TP277 6 | In Stock |
| 6AG1643-0AA01-4AX0 | SIPLUS TP277 6 TOUCH | In Stock |
| 6AV6643-0AA01-1AX0 | SIMATIC TP 277 6" | In Stock |
| SIMATIC TP277 | Description | Inventory status |
Siemens TP277 HMI Manuals PDF Download:
FAQ:
Question: What is the dimension of the Siemens TP277 Touchscrenn?
Answer:The touchscreen of 6AG1643-0AA01-4AX0 SIMATIC TP277 is 5.7 inch,with 138.1 millimeter long and 109.4 millimeter wide
Question: How to backup and restore the Siemens SIMATIC TP277?
Answer:You can back up and restore the following data found in the internal flash memory of the HMIdevice with a PC:br/>• Project and HMI device image
• Password listbr/>• Recipe databr/>Use one of the following tools for backup and restore:br/>• WinCC flexiblebr/>• ProSave
Question: What is the 6AG1643-0AA01-4AX0 Siemens TP277 HMI parts price?
Answer: Submit a fast quote, send VICPAS an email for best price.
