Model
Magelis HMIDT732 HMIDT732FC

Item specifics

Warranty
1 Year VICPAS Warranty
Shipping
DHL/FedEx/UPS/TNT/EMS/Aramex /DPEX
Model
Magelis HMIDT732 HMIDT732FC
Size
15 inch

Review

Description

Schneider HMIDT732 HMIDT732FC Touch Screen Panel Glass Protective Film repair replacement

Order each part separately is available

Schneider HMIDT732 HMIDT732FC Touch Screen Panel Glass Protective Film repair replacement

When connecting the HMIDT732 HMIDT732FC HMI Touchscreen, the COM port's pin 9 setting should be VCC. You can define COM port settings in Vijeo Designer or in the HMIGTO's offline menu. The RS-232C Isolation Unit works with only RS-422/485 (4 wire) communication.Cable-Gateway for Siemens Profibus / MPI (XBT ZG9292) is not supported by HMIDT732 HMIDT732FC.


Magelis HMIDT732 and HMIDT732FC panels offer the following functions:
Display of animated synoptic views with 8 types of animation (pressing the touch panel, color changes, filling, movement, rotation, size, visibility, and value display)
Control, modification of numeric and alphanumeric values
Display of current date and time
Real-time and trending curves with log
Alarm display, alarm log, and management of alarm groups
Multi-window and recipe management
Operator-initiated page calls
Multilingual application management (10 languages at the same time)
Data processing via Java script
Storage of the application and logs on external application memory card in SD format, USB stick, or CFast card
Management of serial printers and barcode readers
Sound Message management



Specifications:

The table below describes the parameters of the HMIDT732 HMIDT732FC touchscreen protective film.

Part Number : HMIDT732 HMIDT732FC
Product Line: Magelis GTU Series
Touchscreen Size: 15 in.
Warranty: 1-Year Warranty
Touch Technology: Resistive Film (analog)
Resolution: DC 5V 1mA
Display colour: 16 million colours
Storage Temp.: -20℃~+70℃
lineation test: ≥1.000.000 times
Input Type: ≥100.000 times

PDF Download:

  • Magelis HMIDT732 User Manual and Product datasheet
  • Magelis HMIDT732FC User Manual and Product datasheet
  • Magelis GTU User Manual PDF

  • Magelis GTU Series Part No.

    Magelis GTU Description Inventory status
    HMIDT351 7"W touch panel In Stock
    HMIDT351FC HMIGTU 7"W touchscreen In Stock
    HMIDT551 10W Touch Advanced Display Available Now
    HMIDT551FC 10W Touch Advanced Display In Stock
    HMIDT542 10.4 Touch Smart Display Available Now
    HMIDT542FC 10.4 Touch Smart Display In Stock
    HMIDT651 12W Touch Advanced Display Available Now
    HMIDT651FC 12W Touch Advanced Display In Stock
    HMIDT642 12.1 Touch Smart Display In Stock
    HMIDT643 12.1 Touch Smart Display Available Now
    HMIDT642FC 12.1 Touch Smart Display In Stock
    HMIDT732 15 Touch Smart Display In Stock
    HMIDT732FC 15 Touch Smart Display In Stock
    HMIDT752 15W Touch Smart Display Available Now
    HMIDT952 19W Touch Smart Display In Stock
    HMIG5U 15 Touch Smart Display Available Now
    HMIG5U2 15 Touch Smart Display In Stock
    Schneider HMIGTU Description Inventory status
