Model
6AG1642-0BD01-4AX0

Item specifics

Warranty
365 Days
Brand
Siemens
Product Line
TP177B 4
Supply
Siemens TP177B HMI Touch Panel and Protecitve film
Size
4 inch
model
6AG1642-0BD01-4AX0

Review

Description

6AG1642-0BD01-4AX0 Siemens SIMATIC HMI TP177 4" Touch Screen Panel, Membrane keypad, Mounting Clips, HMI Case, Power Supply Connector, Gasket, Screws and LCD Display Repair Replacement


6AG1642-0BD01-4AX0 Siemens SIMATIC HMI TP177 4 Touch Screen Panel, Membrane keypad, Gasket, Power Supply Connector, Plastic Cover Body, Mounting Clips, Screws and LCD Display Repair Replacement


6AG1642-0BD01-4AX0 SIPLUS HMI TP 177B 4"color PN/DP for medial exposure with a conformal coating based on 6AV6642-0BD01-3AX0


Touch Panel TP 177B replaces the Touch Panel TP 070/TP 170micro. It can be mounted vertically to provide additional applications. This feature enables its use even when space is restricted. Rature ranges are presently not available.SIPLUS extreme is the product family with ruggedized and refined components on the basis of SIMATIC standard products.


Our new Micro Panels are tailored to applications with SIMATIC S7-200 Micro PLC and provide operating and monitoring functions for small-scale machines and plants. Shortconfiguration and commissioning times, and their configuration in WinCC flexible formhighlights of these panels. In addition, the panels support up to 32 configuration languages and five online languages, including the Asian and Cyrillic character sets


VICPAS supply 6AG1642-0BD01-4AX0 Siemens TP177 touch panel, Overlay, Plastic Shell, Power Supply Connector, Gasket, Mounting Clips, Screws, Terminal Keypad and LCD display. All of them with VICPAS 365-day warranty and support Urgent Worldwide Shipping.






Specifications:

The table below describes the parameters of the 6AG1642-0BD01-4AX0 Siemens TP177 HMI Parts.

Part Number : 6AG1642-0BD01-4AX0
Size 4"
Display TFT
Warranty: 365 days Warranty
Product Line: Siemens TP177
Resolution: 480 x 272;
Number of colors: 256
Control elements: Touch screen and membrane keyboard
MTBF of Backlight 30 000 h
PLC Connection: SIMATIC S7-200


Related Simatic TP177 Part No. :

Siemens TP177 4" Description Inventory status
6AG1642-0BD01-2AX0 SIPLUS TP177B 4" color PN/DP In Stock
6AV6642-0BD01-3AX0 TP177B 4" PN/DP COLOR In Stock
6AG1642-0BD01-4AX0 SIPLUS TP177B 4" color PN/DP In Stock
SIMATIC HMI TP177 4" Description Inventory status

Siemens TP177 HMI Manuals PDF Download:

  • 6AG1642-0BD01-4AX0 Siemens TP177 datasheet pdf
  • Siemens Simatic TP177 Panel manual


  • FAQ:

    Question:What is the use of Siemens TP177 Protective membrane?

    Answer:A protective membrane is available for the HMI device touch screens. The relevant orderinginformation is provided in the Siemens Catalog ST 80. The protective membrane is notincluded in the HMI device package.The self-adhesive membrane prevents the screen from being scratched and soiled. The matsurface of the membrane reduces reflections under unfavorable lighting conditions.The protective membrane can be removed without leaving any adhesive residue on thescreen.


    Question: Which software options are available for the Siemens TP177?

    Answer:"WinCC flexible 2004," for example, refers to the configuration software.The term "WinCC flexible" is used in a general context. The full name, for example"WinCC flexible 2004", is always used when it is necessary to differentiate betweendifferent versions of the configuration software.


    Question: What is the 6AG1642-0BD01-4AX0 Siemens TP177 HMI parts price?

    Answer: Submit a fast quote, send VICPAS an email for best price.
