6AV6545-0CA10-0AX0 Siemens SIMATIC TP270 Touch Panel
- Model
- 6AV6545-0CA10-0AX0
Item specifics
- Warranty
- 365 Days
- Brand
- Siemens
- Product Line
- TP270
- Supply
- Siemens TP270 HMI Touch Panel and Protecitve film
- Size
- 5.7 inch
- model
- 6AV6545-0CA10-0AX0
Review
Description
6AV6545-0CA10-0AX0 Siemens SIMATIC HMI TP270 Touch Screen Panel, Overlay, Plastic Shell, Power Supply Connector, Case Gasket, LCD Gasket, Mounting Clips, Screws and LCD Display Repair Replacement
Order each part separately is available
![6AV6545-0CA10-0AX0 Siemens SIMATIC HMI TP270 Touch Screen Panel, Overlay, LCD Gasket, Case Gasket, Enclosure, Mounting Clips, Power Supply Connector, Screws and LCD Display Repair Replacement 6AV6545-0CA10-0AX0 Siemens SIMATIC HMI TP270 Touch Screen Panel, Overlay, LCD Gasket, Case Gasket, Enclosure, Mounting Clips, Power Supply Connector, Screws and LCD Display Repair Replacement](https://icdn.tradew.com/file/201606/1569362/jpg/7945722.jpg)
6AV6545-0CA10-0AX0 SIMATIC TP 270 6" Touch panel 5.7" STN color display 2 MB configuration memory, configurable with ProTool From Version V6.0
The panel's TP 270 and OP 270 are downgraded models and less expensive but still provide convincing functionality. The HMI devices not only support the classic HMI applications (visualization with WinCC flexible) but also additional applications, such as process diagnostics (ProAgent).
The comprehensive product range allows users to choose the HMI device most suited to their needs. All HMI devices include the following advantages:
• High degree of configuration efficiency
• Configuration simulation on the configuration computer - no PLC required
• Clear display and easy process operation using a Window-Based user interface
• Large selection of predefined screen objects for use during configuration
• Dynamic screen objects, e.g. moving objects
• Uncomplicated and quick handling of recipes and data records in recipe screens and recipe views
• Logging of alarms, process values and login/logout procedures
• Creation of vector graphics using the WinCC flexible configuration software without an external graphics editor,
• Standard connections to SIMATIC S5/DP, SIMATIC S7 and SIMATIC 505, as well as to PLCs from other manufacturers
VICPAS supply 6AV6545-0CA10-0AX0 Siemens TP270 touch panel, Overlay, Mounting Clips, HMI Case, Power Supply Connector, Case Gasket, LCD Gasket, Screws and LCD display. All of them with VICPAS 365-day warranty and support Urgent Worldwide Shipping.
Specifications:
The table below describes the parameters of the 6AV6545-0CA10-0AX0 Siemens TP270 HMI Parts.
Part Number : | 6AV6545-0CA10-0AX0 |
Size | 5.7 inch; |
Display | STN |
Warranty: | 365 days Warranty |
Product Line: | Siemens TP270 |
Resolution: | 640 x 480; |
Number of colors: | 256 |
Control elements: | Touch screen |
MTBF: | 60 000 h |
PLC Connection: | SIMATIC S7-200 |
Related Simatic TP270 Part No. :
Siemens TP270 6" | Description | Inventory status |
6AV6545-0CA10-0AX0 | TP270 6 STN | In Stock |
6AV6545-0CA10-0AX1 | TP270 6 | In Stock |
6AV6545-0CA10-2AX0 | TP270 6 | In Stock |
SIMATIC HMI TP270 6" | Description | Inventory status |
Siemens TP270 HMI Manuals PDF Download:
FAQ:
Question: What is the dimension of the Siemens TP270 Touchscrenn?
Answer:The touchscreen of 6AV6545-0CA10-0AX0 SIMATIC TP270 is 5.7 inch,with 234.5 millimeter long and 181.5 millimeter wide
Question: How to configure with the software WinCC flexible?
Answer:In order to operate a machine or system using an HMI device, the user interface must be configured for the HMI device. This procedure is referred to as the "configuration phase".
Question: What is the 6AV6545-0CA10-0AX0 Siemens TP270 HMI parts price?
Answer: Submit a fast quote, send VICPAS an email for best price.
