10243-LED-C-A173 LCD Screen Repair Replacement
- Model
- 10243-LED-C-A173
Item specifics
- Brand
- VICPAS
- Warranty
- 6 Months
- Product Line
- Siemens LOGO! TDE
- Model
- 10243-LED-C-A173
- Supply
- 10243-LED-C-A173 LCD Display Panel
Review
Description
10243-LED-C-A173 LCD Screen Repair Replacement
10243-LED-C-A173 LCD Display Panel IHM Soft Comfort V6.0 together with the 10243-LED-C-A173 hardware provides the following new features:
Support of 10 languages (EN, IT, NL, ES, FR, CN, DE, TR, RU, JP)
Backlight function for the 10243-LED-C-A173 on-board display and LOGO! TD
Analog modem communication between a PC and 10243-LED-C-A173 (upload, download, online-test)
Online status for LAD circuit programs
Display of PI controller analog output value in a trend view during simulation or online test
Method to delete user program with password in 10243-LED-C-A173 over LOGO! Soft Comfort
Power-on screen for the 10243-LED-C-A173 LCD Display Screen HMI
VICPAS supplies 10243-LED-C-A173 LCD display panel with 6 months warranty and support Urgent Worldwide Shipping.
Specifications:
The table below describes the parameters of the 10243-LED-C-A173 HMI Parts.
| Part Number: | 10243-LED-C-A173 |
| Number of lines: | 6 |
| Character sets: | 6 |
| Warranty: | 12-Months Warranty |
| Product Line: | Siemens LOGO! TDE |
| Rated value (DC): | 24 V |
| Special characters: | 14 |
| System keys: | YES |
| Keyboard fonts: | US English |
| Controllable background colors | 3, white, orange, red |
Related VICPAS HMI Part No. :
| VICPAS HMI Parts | Description | Inventory status |
| Domino A-GP A120 A220 | Domino A-GP A120 A220 Membrane Switch Keypad Replacement Repair | Available Now |
| Domino DB-PL3314 KEYBOARD ASSY FOR A-Series GP | Domino DB-PL3314 KEYBOARD ASSY FOR A-Series GP Membrane Keypad Replacement | In Stock |
| MONTOR II CT speed regulator M550RGB14 M155RGB14 | MONTOR II CT speed regulator M550RGB14 cover M155RGB14 Membrane Keyboard Keypad Housing | In Stock |
| RE21PC25CH16F | TOSOKU Photoelectric Coding Switch RE21PC25CH16F Shaft Φ6.0mm L=16mm | In Stock |
| RE21PC25CH16F | TOSOKU RE21PC25CH16F encoder Panasonic teaching pendant G2/G3 dedicated | Available Now |
| Mindray Bene View T1 Monitor | Mindray Bene View T1 Monitor LCD Screen Touch Screen Repair | In Stock |
| Mindray T1 Monitor | Mindray T1 Monitor HMI Touch Glass LCD Display Panel Repair | Available Now |
| MINDRAY IMEC12 | MINDRAY IMEC12 HMI Touch Screen Panel Repair Replacement | Available Now |
| 10243-LED-C-A173 | 10243-LED-C-A173 LCD Display Panel Repair Replacement | In Stock |
| CMF3P3868 | CMF3P3868 LCD Display Screen Replacement Repair | Available Now |
| HMI Replacement | Description | Inventory status |
Siemens LOGO! TDE series HMI Manuals PDF Download:
FAQ:
Question: How to program with 10243-LED-C-A173 Siemens LOGO! TDE?
Answer: The configuration data of the LOGO!TDE is stored in the CPU of the S7-200. The message texts and the configuration parameters are created with the STEP 7-Micro/WIN V4 SP6 programming software. Additional parameterization software is not required. The operating front design is configured with the Keypad Designer(part of STEP 7-Micro/WIN V4 SP6).
Special data areas are reserved in the CPU of the S7-200 for data exchange with the LOGO!TDE. The LOGO!TDE accesses each of the required functions of the CPU directly via these data areas. User-friendly parameterization takes place via a dedicated LOGO!TDE Wizard in STEP 7-Micro/WIN V4 SP6.
Question: Which is the design of Siemens LOGO! TDE?
Answer: The LOGO!TDE is connected to the S7-200 using the supplied connecting cable. A separate power supply is not required. It is also possible to connect several LOGO!TDE to one S7-200.
Question: What is the 10243-LED-C-A173 LCD Display HMI parts price?
Answer: Submit a fast quote, send VICPAS an email for best price.
