Model
FPM-2150GB-RE FPM-2150GB-R

Item specifics

Warranty
365 Days
Shipping
2-4 workdays
Brand
Advantech
Supply Parts
Touch Panel Keyboard Membrane
Display Type
TFT LCD
Touchscreen
Analog-Resisitive
Part Number
FPM-2150GB-RE FPM-2150GB-R

Review

Description

Advantech FPM-2150GB-RE FPM-2150GB-R Membrane Switch Touch Screen Display Replacement

Order each part separately is available

Advantech FPM-2150GB-RE FPM-2150GB-R Terminal Keypad MMI Panel Screen Repair

Mounting Instruction


When mounting the HMI Advantech FPM-2150GB-RE FPM-2150GB-R Touch Digitizer Glass Terminal Keypad, more than one person should perform the installation. Be careful and prevent accidental damage to the Advantech HMI FPM-2150GB-RE FPM-2150GB-R Keyboard Membrane Touch Screen Panel or personal injury.


Wall Mounting


1. Select the location on the wall for the wall mount plate.
2. Mark the locations of the two plate screw holes on the wall.
3. Drill two pilot holes at the marked locations on the wall.
4. Align the wall mount plate screw holes with the pilot holes.
5. Secure the mount plate to the wall by inserting screws into the two pilot holes and tightening them. Be careful not to drop the Advantech screen FPM-2150GB-RE FPM-2150GB-R Membrane Keyboard Touch Membrane to the ground.
6. Insert four M4 screws into the holes on the panel PC and tighten them to secure the bracket to the rear panel. Check the stability of Advantech FPM-2150GB-RE FPM-2150GB-R touch screen HMI Touch Glass Membrane Switch again.
7. To mount the panel PC on the wall, align the wall mount bracket attached to the panel PC with the wall mount plate on the wall and slide the panel PC downward to hang the bracket on the mount plate.
8. Secure the panel PC in place by tightening the screws into the wall mount bracket.




Specifications:

The table below describes the parameters of the Advantech FPM-2150GB-RE FPM-2150GB-R HMI Touch Glass Operator Keyboard.

Lifespan(Touches): More Than 36 Million
Display Type: TFT LCD
Brand: Advantech
Operating Temperature: -10 ~ +60°C
Touchscreen: Analog Resisitive
Environment: Free From Corrosive Gases
Humidity: 20~80%
Storage Temperature: -40 ~ +80°C
Warranty: 1-Year Warranty
Light Transmission: Above 75%


Related Advantech HMI No. :

Advantech HMI Description Inventory status
FPM-2170GR3B1702-T Advantech Touch Screen Film Front Overlay Replacement In Stock
FPM-2170GR3B1703-T Advantech Protective Film Touch Screen Repair Available Now
FPM-2170GR3B1704-T Advantech Touch Panel Front Overlay Replacement In Stock
FPM-2170GR3B1801-T Advantech Protective Film Touch Membrane Repair Available Now
FPM-2170GR3B1802-T Advantech Touchscreen Front Overlay Replacement In Stock
FPM-2170GR3B1803-T Advantech Front Overlay Touch Screen Film Repair Available Now
FPM-2170GR3B1804-T Advantech Touch Screen Glass Protective Film Replacement In Stock
FPM-2170G-R3BE Advantech HMI Touch Glass Front Overlay Repair Available Now
FPM2170GR3BE1901-T Advantech Protective Film Touch Screen Monitor Replacement In Stock
FPM-2170G-X0AE Advantech Touch Screen Display Front Overlay Repair Available Now
FPM-30CT-T Advantech Protective Film Touch Screen Tablet Replacement In Stock
FPM-3120G-RAE Advantech Front Overlay Touch Digitizer Repair Available Now
FPM-3120G-XAE Advantech Touch Panel Protective Film Replacement In Stock
FPM-3120TV-T Advantech Protective Film Touchscreen Repair Available Now
FPM-3121G-RAE Advantech Touch Panel Front Overlay Replacement In Stock
Advantech HMI Description Inventory status

Advantech HMI Manuals PDF Download:

  • Intelligent HMI and Monitors - Advantech
  • Advantech Industrial loT Systems and Devices Star Product Guide

  • FAQ:

    Question: Which way can I finish the mounting without causing damage to Advantech FPM-2150GB-RE FPM-2150GB-R Touch Digitizer Glass Keypad Membrane?

    Answer: Wall mounting, panel mounting, arm mounting and stand mounting will not do damage to Advantech FPM-2150GB-RE FPM-2150GB-R Touch Panel Keypad Membrane.


    Question: What is the price of Advantech FPM-2150GB-RE FPM-2150GB-R Touch Screen Glass Terminal Keypad?

    Answer: Submit a fast quote, send VICPAS an email for best price.
