ESA Terminals HMI LTP-121F-04 Touch Panel Glass Repair
ESA Terminals HMI LTP-121F-04 Touch Panel Glass Repair
Model
LTP-121F-04

Item specifics

Brand
ESA
Size
12.1 inch
Warranty
365 Days
Product Line
Touch screen terminals
Supply
LTP-121F-04 Touch Screen and Overlay

Review

Description

ESA Touch Screen Terminals LTP-121F-04 Touch Panel Replacement

Order each part separately is available

ESA Touchscreen Terminal LTP-121F-04 Touch Screen Repair Replacement

LTP-121F-04 256-Color TFT LCD 800 x 600 (12.1”) Touch Screen Terminal Repair Kit

LTP-121F-04 operator terminals Main characteristics (modeldependant)::
•High resolution graphicdisplays
•Alarms, passwords, recipes
•Use of Windows® fonts)
•Importation of graphicimages in any format
•Moving graphic objects
•Double driver moves databetween two devices
•Integrated Profibus-DP andCAN


ESA LTP-121F-04 HMI function allows variables and translations to be exported into filesthat can easily be edited using Excel or a text-editor. Once edited, thefile can be re-imported and VTWIN will automatically associate thetranslations, while the variables will be immediately available to be usedto create new project components


VICPAS supply ESA Touchscreen Terminal LTP-121F-04 Touch Panel with 365 days warranty and support Urgent Worldwide Shipping.





Specifications:

The table below describes the parameters of the ESA LTP-121F-04 HMI Parts.

Brand: ESA
Resolution: 800x600
Backlighting: CCFL
Warranty: 6-Months Warranty
Product Line: Touch Terminal
Display Type: Graphic LCD TFT
Touch Screen Matrix: 50x40 (16x15)
Display area size: 9.68x7.28
Size: 12.1"
Part Number: LTP-121F-04


Related ESA VT595 Part No. :

ESA VT595 Description Inventory status
VT595CE1T100 ESA Terminals HMI VT595CE 1T100 Touch Screen Replacement In Stock
VT595CE0T100 ESA Terminals HMI VT595CE 0T100 Touch Panel Replacement In Stock
VT595W0PTDP ESA Terminals HMI VT595W VT595W0PTDP Touch Panel Repair In Stock
VT595W0PTDP ESA Terminals HMI VT595W VT595W0PTDP Touchscreen Repair In Stock
VT595W0PTCN ESA Terminals HMI VT595W VT595W0PTCN Touch Screen In Stock
VT595WAPT00 ESA Terminals HMI VT595W VT595WAPT00 Touch Panel In Stock
VT595WOPTDP ESA Terminals VT595W VT595WOPTDP HMI Panel Glass Repair In Stock
ESA VT TOUCH Description Inventory status


ESA Operator Panel HMI Manuals PDF Download:

  • ESA HMI VT Series Manuals
  • ESA VT Touchscreen Terminal datasheet pdf


  • FAQ:

    Question: How to operate the LTP-121F-04 Terminal with touchscreen?

    Answer:To be able to carry out a change in any editable variable field you musttouch the chosen field on the display and a page appears offering theneeded to modify the field.


    Question: What is the LTP-121F-04 Termination of CAN line?

    Answer:The VT in question integratesthe termination resistances of the serial line (typically 120 ohms)which can be inserted by means of a jumper (preset on 1-2, line not terminated).To activate the termination:
    • Make sure the device is not connected to the power supply.
    • Remove the cover.
    • Identify the jumper unit J2.
    • Position the jumper between pins 2 and 3 (line terminated).
    • Replace the back cover.
    • Reconnect the power supply.


    Question: What is ESA LTP-121F-04 Touch Screen and Protective Flim HMI parts price?

    Answer: Submit a fast quote, send VICPAS an email for best price.

    Common misspellings:

    LT-121F-04
    LTP-121-04
    LTP-12F1-04
    LTP-12lF-04
    LTP-121F-004
