Model
GT1175-VBDA-C

Item specifics

Brand
Mitsubishi
Warranty
365 Days
Product Line
Mitsubishi GOT1000 GT11 series
Supply
GT1175-VBDA-C Touch Front Overlay
Size
10.4 inch
Model
GT1175-VBDA-C

Review

Description

Mitsubishi GOT1000 GT11 series HMI GT1175-VBDA-C Touch Screen Glass Protective Film Repair Kit.

Order each part separately is available

Mitsubishi GT11 series HMI GT1175-VBDA-C Touch panel Front overlay Repair Kit

When connecting or disconnecting converter/cable for GT SoftGOT1000 GT1175-VBDA-C
• When connecting or disconnecting converter/cable that receives 5VDC power
When connecting or disconnecting the converter/cable that receives 5VDC power from a programmable controller, power off the programmable controller and start working.
• When connecting or disconnecting converter/cable that does not receive 5VDC power
When connecting or disconnecting peripheral devices and the cables that do not receive 5VDC power from a programmable controller (receives the power from an external power supply), follow the procedure as below.
1) Be sure to use an earth band or touch a grounded metal object before working to discharge the static electricity from the cables, human body, and others.
2) Power off the personal computer.
3) Power off the converter. When the GT1175-VBDA-C converter/cable have an FG terminal, ground it.
4) Connect/disconnect the converter/cable between the personal computer and programmable controller.
5) Power on the GT1175-VBDA-C converter.
6) Power on the personal computer.
7) Start up the GT1175-VBDA-C software package.


The new GOT1000 GT1175-VBDA-C Touch Screen Tablet Protective Film is suitable for applications in any industry. The new white model GOT provides an additional color option, and the flush frame without the USB port can be cleaned very easily. The GOT can be installed vertically for extra flexibility when installed in confined spaces. VICPAS supply GT1175-VBDA-C Mitsubishi GT11 Protective Film Touchscreen glass with 365 Days warranty and support Urgent Worldwide Shipping.




  Contact Best Price

Specifications:

The table below describes the parameters of the GT1175-VBDA-C Mitsubishi GT11 Touch Digitizer Front Overlay.

Part Number: GT1175-VBDA-C
Display device: STN monochrome (black/white) LCD
Screen diagonal: 10.4 in
Warranty: 365 Days
Product Line: Mitsubishi GT11 Series
Input Power: 24VDC (+10%, -15%)
Operating Temperature: 0 to 55°C
Resolution: 640 × 480 pixels
Storage Temperature: -20°C to 60°C
Cooling Method: Self-cooling


Related Mitsubishi GT11 Series Part No. :

Mitsubishi GOT1000 Description Inventory status
GT1175-VBDA-C Mitsubishi GOT1000 GT11 Touch Protective Film In Stock
GT1175-VNBA Mitsubishi GT11 Touch Screen Overlay Replacement In Stock
GT1175-VNBA-C HMI Panel Glass Overlay GOT1000 GT11 Repair Available Now
GT1175-VTBA Mitsubishi GOT1000 Front Overlay Touch Panel Glass In Stock


Mitsubishi GOT1000 Series HMI Manuals PDF Download:

  • Mitsubishi Graphic Operation Terminal GOT1000 Series Manual
  • Mitsubishi GOT1000 Hmi Catalogue Manual
  • Mitsubishi Electric Corporation GOT1000 Cable Diagram
  • Mitsubishi GOT1000 GT11 User's Manual
  • Mitsubishi GT11 General Description

  • FAQ:

    Question: What is the dimension of GT1175-VBDA-C Mitsubishi GOT1000 GT11 series?

    Answer:The dimension of GT1175-VBDA-C Mitsubishi GOT1000 GT11 HMI is 5.7 inch, which is 135.5mm long and 103.5mm wide.


    Question: What is the GT1175-VBDA-C GOT1000 GT11 touchscreen HMI price?

    Answer: Submit a fast quote, send VICPAS an email for best price.


    Question: What is the installing procedure of the GT1175-VBDA-C multi-color display board?

    Answer:

  • 1. Power OFF the GOT GT1175-VBDA-C.
  • 2. Remove the expansion unit cover (I/F-2 side) of GOT GT1175-VBDA-C rear face.
  • What is the installing procedure of the GT1175-VBDA-C multi-color display board?
  • 3. Install the multi-color display board in the multi-color display board interface.
    (When the extension unit is installed in GOT, remove the installed extension unit. And, do not touch the board in the GOT when install the multi-color display board.)
  • What is the installing procedure of the GT1175-VBDA-C multi-color display board?
  • 4. After the installation, tighten a fixing screw within the specified torque range (0.25 to 0.35N·m).
  • What is the installing procedure of the GT1175-VBDA-C multi-color display board?
