Model
A970GOT-TBA-CH

Item specifics

Brand
Mitsubishi
Warranty
365 Days
Product Line
Mitsubishi GOT-A900 A970GOT series
Supply
A970GOT-TBA-CH Touch Panel Front Overlay
Size
10.4 inch
Model
A970GOT-TBA-CH

Review

Description

Mitsubishi GOT-A900 A970GOT series A970GOT-TBA-CH Touch Screen Hmi Protective Film Repair Kit.

Order each part separately is available

Mitsubishi A970GOT series HMI A970GOT-TBA-CH Front overlay Touch Screen Tablet Repair Kit

Mitsubishi GOT-A900 A970GOT-TBA-CH is installed on the panel surface of control panel or operating panel and connects to the PLC in the control panel. GOT carries out switch operation, lamp display, data display, and message display etc.


Use the Mitsubishi GOT-A900 A970GOT series HMI A970GOT-TBA-CH HMI Touch Screen Overlay to collect data from the programmable controller and temperature controllers. The data can be displayed in graphs and lists. It can also be exported to a personal computer for further analysis. The logging data can be saved in the built-in SRAM even if the power fails.


VICPAS supply A970GOT-TBA-CH Mitsubishi A970GOT Touchscreen glass and Overlay with 365 Days warranty and support Urgent Worldwide Shipping. A GOT-A900 A970GOT-TBA-CH can remotely operate a personal computer that is connected via Ethernet. Connect a USB mouse and keyboard to the USB interface found in the front or at the back of the GOT. This allows you to open files such as manuals that are stored in the personal computer, view the computer's browser, and use engineering tools.




  Contact Best Price


Specifications:

The table below describes the parameters of the A970GOT-TBA-CH Mitsubishi A970GOT Touch Screen Film.

Part Number: A970GOT-TBA-CH
Display device:D-STN color liquid crystal
Screen diagonal: 10.4 in
Warranty: 365 Days
Product Line:Mitsubishi A970GOT Series
Input Power:24VDC (+10%, -15%)
Operating Temperature: 0 to 55°C
Resolution:640 x 480 dots
Storage Temperature:-20°C to 60°C
Cooling Method: Self-cooling


Related Mitsubishi A970GOT Series Part No. :

Mitsubishi GOT-A900 Description Inventory status
A970GOT-LBA Mitsubishi GOT-A900 Touch Screen Monitor Overlay Repair In Stock
A970GOT-LBA-EU Touch Screen Protective Film Mitsubishi GOT900 A970GOT Available Now
A970GOT-LBD Mitsubishi A970GOT Touch Screen Glass Front Overlay In Stock
A970GOT-SBA Mitsubishi GOT900 A970GOT Touch Protective Film In Stock
A970GOT-SBA-EU Mitsubishi A970GOT Touch Screen Overlay Replacement In Stock
A970GOT-SBD HMI Panel Glass Overlay GOT-A900 A970GOT Repair Available Now
A970GOT-TBA Mitsubishi GOT900 Front Overlay Touch Panel Glass In Stock
A970GOT-TBA-B Mitsubishi GOT-A900 Touch Screen Protective Film Repair Available Now
A970GOT-TBA-CH HMI Panel Glass Overlay GOT900 A970GOT Repair Available Now
A970GOT-TBA-EU Mitsubishi A970GOT Touch Digitizer Protective Film In Stock
A970GOT-TBD Mitsubishi A970GOT Touch Screen Overlay Replacement In Stock
A970GOT-TBD-B Mitsubishi A970GOT Touch Screen Overlay Replacement In Stock
A970GOT-TBD-CH HMI Panel Glass Overlay GOT-A900 A970GOT Repair Available Now
A970GOT-TBD-EU Mitsubishi GOT900 Front Overlay Touch Panel Glass In Stock
Mitsubishi A970GOT HMI Description Inventory status


Mitsubishi GOT-A900 Series HMI Manuals PDF Download:

  • A950GOT A951GOT A953GOT A956GOT User's Manual
  • Mitsubishi A985GOT A975GOT A970GOT A960GOT User Manual
  • Mitsubishi GOT-A900 Series User's Manual (Connection System Manual)
  • Graphic Operation Terminal 800 900 series User's Manual
  • Mitsubishi GOT-A900 User's Manual

  • FAQ:

    Question: What is the installation procedure of GOT-A900 A970GOT-TBA-CH?

    Answer: The GOT-A900 A970GOT-TBA-CH mounting procedure is as follows.

  • 1. Insert the GOT-A900 A970GOT-TBA-CH into the panel opening from the front side.
  • What is the installation procedure of GOT-A900 A970GOT-TBA-CH?
  • 2. Place the mounting fixtures (included with GOT) on the mounting fixture attaching part of the GOT-A900 A970GOT-TBA-CH, and fix them by tightening the mounting screws in the torque range of 0.36 to 0.48N·m. (Failure to do so may distort the panel and make a surface waviness on the protective sheet.)
  • What is the installation procedure of GOT-A900 A970GOT-TBA-CH?
  • 3. A protection film is attached on the display section of GOT prior to shipment.
    Remove the film when the installation is completed.

  • Question: What is the A970GOT-TBA-CH GOT-A900 A970GOT protective film HMI price?

    Answer: Submit a fast quote, send VICPAS an email for best price.


    Question: What is the dimension of A970GOT-TBA-CH Mitsubishi GOT-A900 A970GOT HMI Panel Glass?

    Answer:The dimension of A970GOT-TBA-CH Mitsubishi GOT-A900 A970GOT HMI is 10.4 inch, which is 226.2mm long and 183.2mm wide.
