B&R 4B1384.00-K14 Membrane Keypad Keyboard
- Model
- 4B1384.00-K14
Item specifics
- Brand
- B&R
- Membrane Material
- Plastic
- Model
- B&R PANELWARE 4B1384.00-K14
- Warranty
- 1 Year VICPAS Warranty
- Shipping
- DHL/FedEx/UPS/TNT/EMS/Aramex /DPEX
Review
Description
B&R PANELWARE 4B1384.00-K14 Membrane Keypad Keyboard Repair
Order each part separately is available
Energy provision for the electronics of the B&R PANELWARE 4B1384.00-K14 MMI is done from the controller in order to save on volume and power in the panel. A 2 x 20 character LCD is used as the 4B1384.00-K14 display. An 4B1384.00-K14 LED background lighting with an automatic shut-off and a practically unending life expectancy has also been integrated. In addition to the alphanumeric display, operator guidance is also assisted with key LEDs.
The B&R PANELWARE 4B1384.00-K14 COMPACT MMI in combination with the COMPACT PLC BRCOMP1-0 makes an extra low cost and very attractive automation package (control and visualization). It is also possible to use the COMPACT MMI with a MINI, MIDI, MULTICONTROL or an M264. All 4B1384.00-K14 keys are equipped with key LEDs which can be switched on and off individually. The key LEDs can be used to make application control easier to see and to simplify panel operation. To control a certain LED, the respective key code (x) is given (valid key codes can be found under point "Key Code Requests").
Specifications:
The table below describes the parameters of the 4B1384.00-K14 B&R PANELWARE Membrane Keypad Keyboard.
| Part Number : | 4B1384.00-K14 |
| Product Line: | PANELWARE |
| Warranty: | 365 Days Warranty |
| Input Power | 24 VDC |
| Display Type: | TFT color |
| Mounting position: | Vertical |
| Input Type: | Keypad |
| Serial interface Type: | RS232 |
Related B&R PANELWARE Series Part No. :
| B&R PANELWARE | Description | Inventory status |
| 4D1165.00-K05 | B&R PANELWARE Operator Keyboard Repair | In Stock |
| 4D1165.00-K08 | PANELWARE B and R Keyboard Membrane Replacement | Available Now |
| 4B1270.00-K09 | B&R PANELWARE Switch Membrane Repair | In Stock |
| 4B1270.00-K15 | PANELWARE B and R HMI Terminal Keypad | Available Now |
| 4B1270.00-K18 | B&R PANELWARE Keyboard Membrane Repair | In Stock |
| 4B1384.00-K07 | B&R PANELWARE Membrane Keypad Keyboard | In Stock |
| 4B1384.00-K08 | B&R PANELWARE Switch Membrane Repair | In Stock |
| 4B1384.00-K14 | B and R PANELWARE Membrane Keypad Replacement | Available Now |
| 4B1384.00-K16 | B&R PANELWARE HMI Switch Membrane Repair | Available Now |
| B and R PANELWARE | Description | Inventory status |
B&R PANELWARE Manuals PDF Download:
FAQ:
Question:How to remove B and R PANELWARE COMPACT 4B1384.00-K14 MMI?
Answer:
• Remove spring clips
• Remove panel
• Remove and reapply sealant before a new installation
• The mounting pins do not have to be removed
Question:How can the PANELWARE 4B1384.00-K14 service life of backlights be extended?
Answer:
• Set the display brightness to the lowest value comfortable for the eyes.
• Use dark images.
• Reducing the brightness by 50% can increase the half-brightness time by approximately 50%.
