Model
X2 pro10

Item specifics

Brand
Beijer
Warranty
365 Days
Product Line
X2 pro
Resution
1024 × 600 pixels
Supply
Beijer X2 pro 10 Touch Screen and Overlay

Review

Description

Beijer HMI X2 Pro 10 630000305 Touchscreen Repair Replacement


 Beijer HMI X2 Pro 10 630000305 Touchscreen Repair Replacement

Beijer X2 Pro 10 630000305 10 INCH HMI with iX runtime HMI Repair kit


• 1024 × 600 pixel (16:9)
• TFT-LCD touch screen
• 1.5 GB application memory
• Ethernet 2x100 Mbit
• -10°C to +60°C operating temperature
• CE, FCC, KCC, UL approvals
• DNV GL, KR, LR, ABS, CCS, BV, NK marine approvals

X2 pro includes a wide range of high performance industrial panels from ultra-compact 4-inch to 21-inch panels designed for demanding applications. All with the high performance of powerful ARM Cortex-A9 processors, the latest screen technology and a wide range of connectivity options to cover all your automation needs.

VICPAS supply Beijer X2 Pro 10 Touch Panel with 365 days warranty and support Urgent Worldwide Shipping.




  Contact Best Price


Specifications:

The table below describes the parameters of the 630000305 Beijer X2 Pro 10 HMI Parts.

Brand: Beijer
Part number: 630000305
Size:10.1 INCH
Warranty: 365 Days Warranty
Product Line:X2 Pro 10
Size diagonal:1024 × 600 pixels
Display type: TFT-LCD
Touch type:Resistive
Input voltage:20 - 30 V DC
Power: 12W


Beijer X2 Pro 10 Touch Panel HMI Manuals PDF Download:

  • Beijer X2 pro Series Maintenance Manuals
  • Beijer X2 pro 10 HMI datasheet pdf


  • FAQ:

    Question: How to install the Beijer X2 Pro 10 Touch Panel?

    Answer:1. Unpack and check the delivery. If damage is found, notify the supplier.
    2. To cut a correct opening for the operator panel, use the cut out dimensionsin the outline drawing. Aseparate cut out drawing is available for download from theBeijer Electronics web site. Formore information, see sections Operator Panel Drawings andTechnicalData.
    3. Install the operator panel into the cutout.
    4. Secure the operator panel in position by screwing the slotted thumb screwclockwise, allowing the built-in bracket toflipout and tightenagainst thecabinet
    5. Secure the operator panel in position using the built-in brackets or screws,depending on the panel type.
    6. In caseswhere the front panel seal (IP54 or greater, NEMA-4X) is critical,a torquewrench shouldbeused to ensure all screws are torquedwithinthespecification above


    Question: Why the Beijer X2 Pro 10 HMI have the chemical resistance?

    Answer:Autoflex EBA180L covers the overlay surrounding the screen.


    Question: What is Beijer X2 Pro 10 Touchscreen and Overlay HMI parts price?

    Answer: Submit a fast quote, send VICPAS an email for best price.
