Model
T070C-5RB0104N-0A18R0-200FH

Item specifics

Brand
Higgstec Touch Screen
Display Size
7 inch
Warranty
365 Days
Shipping
2-4 workdays
Supply Parts
T070C-5RB0104N-0A18R0-200F Touchscreen Panel Glass
Touch screen panel type
Resistance touch screen

Review

Description

Higgstec Touch Screen T070C-5RB0104N-0A18R0-200FH Repair Replacement


Higgstec T070C-5RB0104N-0A18R0-200FH HMI Panel Glass repair replacement

Higgstec T070C-5RB0104N-0A18R0-200FH True Flat Resistive touch solution combines the simplicity, versatility and durability of our 5-wire resistive technology with an attractive zero-bezel design. The flush surface is easier to clean and there will be no dust or dirt buildup or water leakage into the bezel, making it an excellent solution for sterile or dust free environments such as medical clinics, scientific laboratories, restaurants or food processing areas. What's more, you now also incorporate features such as logos or hotkey buttons on the cover design.


Benefits of Higgstec T070C-5RB0104N-0A18R0-200FH True Flat Resistive Touch Digitizer Glass Solution
(1) Appearance
Flush zero-bezel surface, more visually attractive surface, more visually attractive, more customization and easier to keep clean, prevents dirt/ dust build-up or water to enter via bezel
(2) Durability
Tested for up 35 million touches. Higgstec T070C-5RB0104N-0A18R0-200FH Touchscreen Panel Glass High-temperature production process ensures excellent durability even in harsh operating temperatures.
(3) Operation
Precise linearity, stable and no drifting. Versatile input: fingers, gloves, passive stylus.
(4) Mechanical
Higgstec T070C-5RB0104N-0A18R0-200FH Touch Screen Monitor 5-Wire resistive design ensures long-lasting stability and functionality even if surface is scratched or broken. Hotkey buttons can be incorporated onto front bezel.




Specifications:

The table below describes the parameters of the Higgstec T070C-5RB0104N-0A18R0-200FH Touch Panel Spare Part.

Number of Touches: Single
Product Line: Higgstec
Interface: USB / RS232 / COMBO
Warranty: 1-Year Warranty
Touch Activation Force: Stylus ≦ 50g
Display Size: 7 inch
Linearity: X ≦ 1.5%, Y ≦ 1.5%
Tail Options: FFC/ FPC tail
Resolution: 4096 X 4096
Response time: ≦ 20ms


Related Higgstec Touch Screen HMI Part No. :

Higgstec Touch Screen Description Inventory status
T070C-5RB010N-0A11R0-200FH Higgstec Touch Screen Glass Replacement In Stock
T070C-5RB094N-0A11R0-076FW Higgstec Touch Screen Panel Replacement Available Now
T070S-5RB003N-0A11R0-080FH Higgstec HMI Touchscreen Repair Part In Stock
T070S-5RB003N-0A11R0-080FH-C Higgstec HMI Touch Screen Glass Available Now
T070S-5RB013N-0A11R0-080FH Higgstec Touch Screen Panel Repair In Stock
T070S-5RB013N-0A11R0-080FH-C Higgstec Touch Membrane Repair In Stock
T070S-5RB018X-0A11R0-080FH Higgstec HMI Touch Glass Repair In Stock
T070S-5RBA05N-0A11R0-200FH Higgstec HMI Panel Glass Replacement Available Now
T070S-5RBA13N-0A11R0-080PN Higgstec Touch Digitizer Glass Repair Available Now
T070S-5RBA18X-0A18R0-080FH Higgstec Touch Screen Monitor Repair In Stock
Higgstec Touch Panel Description Inventory status

Higgstec Touch Screen Panel HMI Manuals PDF Download:

  • Higgstec T057S-5RBC02X-0A18R0-150FH Manual Datasheet
  • Higgstec T057S-5RBC06X-3A11R4-080FH Manual Datasheet

  • FAQ:

    Question: How to test Higgstec T070C-5RB0104N-0A18R0-200FH Touch Screen Panel Glass?

    Answer:
    Linearity Condition
    Step 1: short RT and RL (or short RL and LL).
    Step 2: apply voltage DC 5V.
    Step 3: short LT and LL (or short RT and LT).
    Step 4: apply grounding.
    Step 5: draw points along LX and LY at 5.0mm intervals within pattern area and detect the voltage at SG.
    Step 6: measure the voltage differences between RT and LT (or RT and RL)
    How to test Higgstec T070C-5RB0104N-0A18R0-200FH Touch Screen Panel Glass?
    How to test Higgstec T070C-5RB0104N-0A18R0-200FH Touch Screen Panel Glass?
