3M MICROTOUCH PN 10043 HMI Touch Screen Monitor
3M MICROTOUCH PN 10043 HMI Touch Screen Monitor
3M MICROTOUCH PN 10043 HMI Touch Screen Monitor
3M MICROTOUCH PN 10043 HMI Touch Screen Monitor
Model
3M MICROTOUCH PN 10043

Item specifics

Size
9.6 inch
Warranty
365 Days
Supply
3M MICROTOUCH PN 10043 Touch Screen Repair
Model
3M MICROTOUCH PN 10043

Review

Description

3M MICROTOUCH PN 10043 HMI Touch Screen Panel Repair


3M MICROTOUCH PN 10043 HMI Touchscreen Panel Glass Repair Kit

3M MICROTOUCH PN 10043 Touch Screen Panel Glass IHM Highlights
• 10.4” TFT color display
• High brightness
• Sunlight-readable
• SVGA (800x600 pixel) resolution
• 64K colors
• Resistive touchscreen
• 10/100 Ethernet interface
• USB port
• Connection to industrial bus systems using optional plug-in modules
• Compatible with video input module
• 64 MB user memory
• Compatible with local I/O


The 3M MICROTOUCH PN 10043 HMI Panel Glass HMI is a state-of-the-art HMI device featuring a high-brightness sunlight-readable 10.4” TFT color display with SVGA (800x600) resolution and resistive touchscreen. 3M MICROTOUCH PN 10043 Touch Screen Panel Glass HMI has been specifically designed for use under extreme illumination conditions. Support for 64K colors in the brilliant TFT display will increase the realism of the images. The integrated 10/100 Ethernet interface enhances connectivity in complex control systems.





Specifications:

The table below describes the parameters of the 3M MICROTOUCH PN 10043 Touchscreen Panel.

Part Number: 3M MICROTOUCH PN 10043
Display Type: TFT LCD
Resolution: 640x480 pixel
Backlight: CCFL
Warranty: 365 Days
Input Power: 24VDC (+10%, -15%)
Operating Temperature: 0 to 45 °C
Display Size: 10.4 in
Touch screen: Resistive
Product Line: Touch Screen Panel


FAQ:

Question: How to cleaning 3M MICROTOUCH PN 10043 Touch Panel Glass IHM faceplates?

Answer: The equipment must be cleaned only with a soft cloth and neutral soap product. Do not use solvents.


Question: What is 3M MICROTOUCH PN 10043 Touchscreen Calibration?

Answer:

  • Standard calibration:
  • 1. Recall Configuration Mode
  • 2. Touch the CLEAR key on the 3M MICROTOUCH PN 10043 screen until a small round symbol will appear on the top right corner of the screen
  • 3. touch and hold the symbol until it will move to the low left corner of the 3M MICROTOUCH PN 10043 screen
  • 4. touch and hold the symbol until the indication to touch the ← key will be displayed on the screen
  • 5. touch and hold the key ← until the indication to touch the ↓ key will be displayed on the screen
  • 6. touch and hold the key ↓ until the indication to touch the Enter key will be displayed on the screen
  • 7. touch and hold the Enter key until the panel will switch to Operation Mode (if a valid project is loaded in the memory)
  • Emergency calibration.
  • The Emergency calibration procedure should be used in all cases when it would result not possible to go to calibration using the standard procedure.
  • 1. Switch of the unit
  • 2. turn on the unit
  • 3. tap in the middle of the touchscreen with a frequency of about one second until the operator panel will enter the Calibration Mode
  • 4. perform the standard calibration procedure.
