Model
VT420 1SF000

Item specifics

Brand
ESA
Warranty
180 Days
Product Line
VT Text
Supply
VT420 Membrane Keypad

Review

Description

ESA TEXT HMI VT420 VT4201SF000 Membrane Keyboard Replacement

ESA TEXT HMI VT420 VT4201SF000 Membrane Keyboard Repair Replacement

VT420 1SF000 ESA VIDEO TERMINAL (VT) is a device that allows the user to control orsimply monitor a productive process. It can send commands using configuredby the user; it can send data determining the process on hand andcan display information deriving from the productive process. The informationcan be in the form of an Alarm, an Information (Info-) Message or inbinary data format.


VICPAS supply ESA TEXT HMI VT420 membrane switch with 6 months warranty and support Urgent Worldwide Shipping.





Specifications:

The table below describes the parameters of the ESA VT4201SF000 HMI Parts.

Brand: ESA
Display Type: Graphic LCD 16 colors STN
Resolution: 320x240
Warranty: 6-Months Warranty
Product Line: VT TEXT
Display Type: TEXT LCD
Display area size: 4.55x3.43
Columns by Rows: Depending on used Font
Size: 5.7"
Part Number: VT4201SF000


Related ESA VT420 Part No. :

ESA VT420 Description Inventory status
VT420L1SF000 ESA Text HMI VT420L1SF000 Membrane Keypad Repair Replacement In Stock
VT42025F000 ESA Text HMI VT420 VT42025F000 Membrane Keyboard Replacement In Stock
VT4201SF000 ESA Text HMI VT420 VT4201SF000 Membrane Switch Replacement In Stock
VT4202SF000 ESA Text HMI VT420 VT4202SF000 Membrane Keypad Replacement In Stock
VT4202SFF00 ESA Text HMI VT420 VT4202SFF00 Terminal Keypad Repair Part In Stock
ESA VT TEXT Description Inventory status


ESA VT420 Operator Panel HMI Manuals PDF Download:

  • ESA HMI VT Series Manuals
  • ESA VT TEXT HMI datasheet pdf


  • FAQ:

    Question: How to adjust the contrast on the ESA VT420 Display?

    Answer:To improve the quality of the representation on the display it may be necessaryto adjust its contrast. This can be done by rotating the trimmer (C) atthe back of the VT ; turn it (using a small screwdriveror a trimmer tool) in one direction and, if the display quality worsens,turn it the other way.


    Question: What is the VT420 Termination of CAN line?

    Answer:The VT in question integratesthe termination resistances of the serial line (typically 120 ohms)which can be inserted by means of a jumper (preset on 1-2, line not terminated).To activate the termination:
    • Make sure the device is not connected to the power supply.
    • Remove the cover.
    • Identify the jumper unit J2.
    • Position the jumper between pins 2 and 3 (line terminated).
    • Replace the back cover.
    • Reconnect the power supply.


    Question: What is ESA VT420 mebrane keyboard HMI parts price?

    Answer: Submit a fast quote, send VICPAS an email for best price.

    Common misspellings:

    V4201SF000
    VT201SF000
    VT401SF000
    VT421SF000
