91-28115-000 Touch Screen Film Replacement
91-28115-000 Touch Screen Film Replacement
91-28115-000 Touch Screen Film Replacement
91-28115-000 Touch Screen Film Replacement
Model
91-28115-000

Item specifics

Shipping
2-3 workdays
Warranty
365 Days
Touchscreen
5-Wire-Resistive
Supply Parts
Touch Screen Display
Part Number
91-28115-000
Size
15''
Brand
Vicpas

Review

Description

91-28115-000 HMI Touch Screen Panel Glass Replacement


91-28115-000 Touchscreen Repair

Disassembly Instructions


Follow the basic steps that should typically be followed to remove components and materials.
1. Disassembly 15 pcs screw to remove the rear cover. Pay attention not to drop 91-28115-000 Touch Screen Glass to the ground.
2. Disassembly 3 pcs screw to remove the control Board.
3. Disassembly 4 pcs screw to remove the AD board.
4. Disassembly 4 pcs screw to remove the power board and ensure 91-28115-000 Touch Panel is disconnected.
5. Disassembly 3 pcs screw to remove the lO bracket.
6. Take 91-28115-000 Touch Digitizer Glass off before disassembly 9 pcs screw 4 pcs post to remove the middle bracket.
7. Disassembly screw 4 pcs to separate the LCD bracket left and right with LCD module.
8. Disassembly 1 pcs screw to remove the LED board.
9. Remove the waterproof from front bezel of 91-28115-000 HMI Panel Screen.




Specifications:

The table below describes the parameters of 91-28115-000 Touch Screen Monitor.

Storage Humidity: 95% RH
Display Size: 15''
Display Type: Free From Corrosive Gases
Storage Temperature: -20 ~ 60 °C (-4 ~ 140 °F)
Operating Temperature: 0 ~ 50 °C (32 ~ 122 °F)
Brand: Vicpas
Warranty: 1-Year Warranty
Environment: Free From Corrosive Gases
Touchscreen Type: 5-Wire-Analog-Resisitive
Lifespan: 36 Million Touches


Advantech HMI Manuals PDF Download:

  • FPM-51x1G_Data Sheet
  • Intelligent HMI and Monitors - Advantech

  • FAQ:

    Question: How to maintain 91-28115-000 Touch Screen Monitor?

    Answer: When cleaning 91-28115-000 Touch Panel, use only a damp cloth. Do not use liquid or spray detergents. Ensure the Touch Digitizer Glass is placed on a stable surface during installation. Avoid direct sunlight exposure for the Touch Screen Film.


    Question: What is the price of 91-28115-000 Touch Screen Panel?

    Answer: Submit a fast quote, send VICPAS an email for best price.

    Common misspellings:

    1-28115-000

    9-28115-000

    91-28115-00

    91-288115-000

    91-281150-00
