Beijer EXTER K30m 602220102 Monochrome Membrane Switch
- Model
- EXTER K30m
Item specifics
- Brand
- Beijer
- Warranty
- 180 days
- Product Line
- EXTER operator panels
- Size diagonal
- 240 x 64 pixels
- Supply
- Beijer EXTER K30m Membrane Switch
Review
Description
Beijer EXTER K30 m 603111201 Beijer EXTER Series Membrane Keyboard Repair Replacement
EXTER K30 m monochrome keypad HMI membrane switch replacement
The EXTER K30 m 603111201 features:
•240 x 64 pixels
FSTN display
240 x 64 pixelsProject storage 12 MB
Operating temperature 0 to +50 °C
Ethernet and serial
8 keys / 16 LEDs
The EXTER K30 is an efficient interface for presentation of mainly textual data. Its compact format offers basic HMI functionality and support for communication expansion modules. The six function keys can be used for controlling, with an explanatory text in the display or on a text strip, and the six LEDs for status indication.All EXTER operator panels are configured with the software tool Information Designer.
VICPAS supply Beijer Exter EXTER K30 m membrane switch with 6 months warranty and support Urgent Worldwide Shipping.
Specifications:
The table below describes the parameters of the 603111201 Beijer EXTER K30 m HMI Parts.
| Brand: | Beijer |
| Numerical keypad: | YES |
| Input fuse: | Internal DC fuse |
| Warranty: | 6-Months Warranty |
| Product Line: | Beijer EXTER K30 m |
| Size diagonal: | 240 x 64 pixels |
| Part Number: | 602220102 |
| Backlight: | LED with dimming |
| Input voltage: | 20 - 30 V DC |
| Display type: | Monochrome FSTN |
Beijer EXTER K30 m Operator Panel HMI Manuals PDF Download:
FAQ:
Question: How to ground the Beijer EXTER K30 m Operator Panel?
Answer:1. The operator panel’s mounting clamps do not provide a secure grounding connectionbetween the panel and the device cabinet.
2. Connect a 2.5 mm2 wire between the operator panel’s quick-connect plinth andthe panel chassis.
3. Connect a 6 or 4 mm2 wire or grounding braid between the panel’s chassis andthe closest grounding point on the door.
4. Connect a strong but short grounding braid between the door and the devicecabinet.
5. Twist the cables onto the 24 V DC feed.
6. A ferrite core suppresses disturbances to the 24 V feed.
Question: Why are Beijer 603111201 membrnae keypad with the chemical resisitace?
Answer:Beacuse Autotex F157 covers the membrane keyboard.
Question: What is EXTER K30 m 603111201 Beijer E1000 Series Operator Panel mebrane keyboard HMI parts price?
Answer: Submit a fast quote, send VICPAS an email for best price.
