6AV6647-0AB11-3AX0 SIMATIC HMI KTP600 BASIC MONO PN Panel
- Model
- 6AV6647-0AB11-3AX0
Item specifics
- Brand
- Siemens
- Warranty
- 365 Days
- Product Line
- KTP600 Basic
- Supply
- Siemens KTP600 HMI Touch Panel LCD Display
- Size
- 5.7 inch
- Model
- 6AV6647-0AB11-3AX0 Housing
Review
Description
6AV6647-0AB11-3AX0 Siemens SIMATIC HMI KTP600 BASIC MONO PN Touchscreen Glass, HMI Case, Overlay, Mounting Clips, Power Supply Connector, Gasket, Screws and LCD Display Repair Replacement
Order each part separately is available
6AV6647-0AB11-3AX0 SIMATIC HMI KTP600 Basic mono PN, Basic Panel, Key/touch operation, 6" STN display, 4 gray levels, PROFINET interface, configurable as of WinCC flexible 2008 SP2 Compact/ WinCC BasicV10.5/ STEP 7 Basic V10.5, contains open-source software, which is provided free of charge see enclosed CD
6AV6647-0AB11-3AX0 SIMATIC HMI KTP600 Basic Color DP, Basic Panel, Key/touch operation, 6" TFT display, 256 colors, MPI/PROFIBUS DP interface, configurable as of WinCC flexible 2008 SP2 Compact/ WinCC Basic V11/ STEP 7 Basic V11, contains open-source software, which is provided free of charge see enclosed CD.
The visualization of Siemens KTP600 Basic allows for considerably increased process quality with compact plants or smaller applications. Featuring all important HMI basic functions, SIMATIC HMI Basic Panels Generation thus opens up completely new possibilities in terms of operation and monitoring also in the field of mechanical engineering at a handsome price. Besides, These also support vertical configuration. Their high resolution and color depth of 64,000 colors facilitate improved process visualization. The displays’ brightness is dimmable up to 100 %, offering optimum flexibility.
VICPAS supply 6AV6647-0AB11-3AX0 Siemens KTP600 Basic Plastic Cover, touch panel, Overlay, Gasket, Power Supply Connector, Screws, Mounting Clips and LCD display. All of them with VICPAS 365 days warranty and support Urgent Worldwide Shipping.
Product Video:
The video below describes the product details of the 6AV6647-0AB11-3AX0 SIMATIC HMI KTP60 Basic Touch Panel Glass, Overlay and LCD Display Repair Replacement Siemens KTP600 Basic HMI parts, include touch screen panel, protective film, Housing with lcd display.
Specifications:
The table below describes the parameters of the 6AV6647-0AB11-3AX0 Siemens KTP600 Basic HMI Parts.
| Part Number : | 6AV6647-0AB11-3AX0 |
| Touchscreen: | colour LCD display |
| Design of display | STN |
| Warranty: | 365 days Warranty |
| Product Line: | Siemens KTP600 Basic |
| Active power input, typ.: | 6 W |
| Mounting position: | vertical |
| Key Features: | Touch screen support |
| Language: | Worldwide |
| Number of colors | 4; Grayscales |
Related Siemens KTP600 Basic Part No. :
| Siemens KTP600 Basic | Description | Inventory status |
| 6AV6647-0AB11-3AX0 | SIMATIC HMI KTP600 BASIC MONO PN | In Stock |
| 6AV6647-0AC11-3AX0 | SIMATIC HMI KTP600 BASIC COLOR DP | In Stock |
| 6AV6 647-0AD11-3AX0 | SIMATIC HMI KTP600 BASIC COLOR PN | Available Now |
| 6AG1647-0AD11-2AX0 | SIPLUS KTP600 BASIC COLOR PN | In Stock |
| SIMATIC HMI KTP600 Basic | Description | Inventory status |
Siemens KTP600 Basic HMI Manuals PDF Download:
FAQ:
Question: What is the size of 6AV6647-0AB11-3AX0Siemens KTP600 touch panel??
Answer:The Siemens KTP600 Basic TouchScreen is 5.7-inch.It is 138.1 millimeter long and 109.4 millimeters wide.
Question: Which software for Siemens Simatic KTP600 Basic to program?
Answer:WinCC (TIA Portal) is the software for all HMIapplications – from simple operation solutions withBasic Panels, down to process visualizations onPC-based multi-user systems.independentconfiguration data on various targetsystems without conversion. The interface adjustsitself to the functional properties of the target device.Joint project data (alarm class, project texts, etc.) arecentrally managed in the TIA Portal and can be usedacross different devices. Furthermore, an assistant forHMI configurations is available independently of thedevice which supports the rapid and easy creation ofthe visualization’s basic structure.
Question: What is the 6AV6647-0AB11-3AX0 Siemens KTP600 Basic HMI parts price?
Answer: Submit a fast quote, send VICPAS an email for best price.
